Molex 505570-0701

mpn505570-0701
brandname: Molex Incorporated
manufacturername: Molex Incorporated

MOLEX - 505570-0701 - Connector Housing, Micro-Lock Plus 505570, Receptacle, 7 Positions, 2 mm, 505572 Crimp Terminal

MOLEX - 505570-0701 - Connector Housing, Micro-Lock Plus 505570, Receptacle, 7 Positions, 2 mm, 505572 Crimp Terminal

zoom

Brand: Molex
PartNumber: 505570-0701
Model: 505570-0701
Manufacturer: Molex
Label: Molex

Attributes

Key	Value
Circuit	7 Circuits
Circuits (maximum)	7
Color	Black
Color - Resin	Black
Family Name	Micro-Lock PLUS
Flammability	94V-0
For Use With	Micro-Lock PLUS Vertica.
Gender	Receptacle
Keying to Mating Part	None
Lock to Mating Part	Yes
Material - Resin	Polyester
Number of Rows	1
Operating Temperature	-40 to 221 F (-40 to 10.
Package Quantity	1
Package Type	Bag
Panel Mount	No
Pitch	2 mm
Pitch - Mating Interface	2.00mm
Pitch - Termination Int.	2.00mm
Polarized to Mating Part	Yes
Series	505570 Series
Temperature Range - Ope.	-40? to +105?C
UL	E29179

All Prices

Img	Seller	Supplier SKU	Min Price	MOQ	In Stock	Lead Time	Brand	Weight	Preferred Tier
	Newark	34AC0211	0.04	1	3		MOLEX		0.04 @ 1
	Waldom	MOLEX 505570-0701	0.117	500	54878		MOLEX		0.117 @ 500
	jensentools.com	10192403	0.16	1	54878		Molex		0.16 @ 1
	Zoro	G400442889	0.21	500	476		Molex		0.21 @ 500
	us.rs-online.com	71204941	0.25908	1	476		Molex Incorporated		0.25908 @ 1
	RS Delivers	186-5082	0.2616	1	200		Molex		0.2616 @ 1
