| Application | Power Transmission |
| Bearings | Ball |
| Country of Origin (subject to change) | Germany |
| Dimension A | 5.91" |
| Dimension B | 6.3" |
| Dimension BA | 2.95" |
| Dimension C | 18.86" |
| Dimension D | 3.54" |
| Dimension E | 4.33" |
| Dimension F | 5.12" |
| Dimension H | 0.35" |
| Dimension Z | 4.41" |
| Enclosure | TEFC |
| Finish | Unpainted |
| Full Load Amps | 3.66/1.83 |
| Gear Case Material, Housing | Die Cast Aluminum Alloy |
| Gear Ratio | 43.2:1 |
| Gear Type, Gears | Helical |
| Gearmotor Enclosure | Totally Enclosed Fan-Cooled |
| Gearmotor Mounting Position, Mounting | Horizontal |
| Gearmotor Phase, Phase | 3 |
| Gearmotor Rotation | CW/CCW |
| Gearmotor Shaft Orientation, Shaft Orientation | Inline |
| Gearmotor Shaft Type | Single |
| Gearmotor Type, Item | AC Gearmotor |
| Gearmotor Voltage | 230/460VAC |
| Height (Dimension O) | 6.61" |
| Hz | 60 |
| Input HP | 1 |
| Insulation Class | F |
| Keyway Size, Keyway Size Type | 1/4" Square x 1-1/4" |
| Length Less Shaft | 16.89" |
| Lubrication | Mineral Oil |
| Max. Ambient Temp. | 40 Degrees C |
| Max. Torque | 1653 in.-lb. |
| Motor Type | 3-Phase |
| Nameplate RPM, No Load RPM | 40 |
| Overhung Load | 981 lb. |
| Rotation | Reversible |
| RPM @ 50 Hz | 33 |
| RPM Range | 31 to 50 |
| Seals | Double Lip |
| Service Factor | 0.9 |
| Shaft Dia. (Dimension U) | 1" |
| Shaft Length (Dimension V) | 1.97" |
| Standards | UL Recognized/CSA/CE |
| Starting Torque | 38.1 in.-lb. |
| Voltage | 230/460 |
