brand:
manufacturer:
Description:
100-12-1-40-64-0-0 NOSHOK | Search our online catalog of Industrial Hydraulics. Start your quote online to connect with our team of technical experts for support.
Attributes
| Key | Value |
|---|---|
| 10 Series Heavy-Duty Sanitary Pressure Gauges | None (0)Maximum Indicating Pointer - 4" Gauge (1)Adjustable Pointer - 4" Gauge (2)Polycarbonate Lens - 2-1/2" Gauge (3)Polycarbonate Lens - 4" Gauge (3) |
| Accuracy | 1 |
| Ambient Temperature Range | 25 to 140 |
| Application | Food & beverage processingPasteurization systemsPharmaceuticalMedical |
| Bayonet Ring Material | Electropolished 304 Stainless Steel |
| Category | 10 Series Heavy-Duty Sanitary Pressure Gauges |
| Clamp Size | 1-1/2 |
| Connection Location | 1-1/2" or 2" ASME-BPE Sanitary Clamp, 316L stainless steel, Diaphragm 316L stainless steel, electropolished to 32 in Ra or better |
| Dial/Display Size | Aluminum, white background with black scale. |
| Fill Liquid | Glycerin, USP Grade |
| Gauge Fill Fluids | None |
| Gauge Size | 4 |
| Lens/Display Material | Safety Glass |
| Material | Electropolished 304 Stainless Steel |
| Measuring Element | 316 Stainless Steel "C" Tube |
| Media Temperature Range | -40 to 300 |
| Movement | Stainless Steel |
| Note | Autoclave requires the addition of optional laminated safety glass lens |
| Operating Temperature [Max] | 60 |
| Operating Temperature [Min] | -4 |
| Options | None |
| Options and Accessories | Maximum Indicating Pointer (1), Adjustable Pointer (2), Polycarbonate Lens (3), None |
| Pointer | Balanced Aluminum, Black Finish |
| Pressure Range | 0 to 400 |
| Price: | $741.66 |
| SchemaID | 101737 |
| Seal Fill Fluid | Glycerin |
| Series | 10 Series Heavy-Duty, Bottom Connected |
| Syndication | 1 |
| Type | Pressure Gauge |
| Unit | 1 |
