25-310-0-1-7-2-6-3-1 NOSHOK | Search our online catalog of Industrial Hydraulics. Start your quote online to connect with our team of technical experts for support.
Attributes
| Key ^ | Value |
|---|---|
| Accuracy | 2.0 |
| Accuracy Grade | B |
| Accuracy Standard | American Society of Mechanical Engineers (ASME) B40.3 |
| Application | Power transformersPaper millsRefineriesPetrochemicalOil and gasChemicalHVAC/RFood processingPharmaceutical |
| Bulb Dimensions | 2-5/8 x 3/8 |
| Capillary Length | 6 |
| Capillary Types/Materials | Copper, Stainless Steel |
| Category | 300 Series Vapor Actuated Remote Dial Indicating Thermometers |
| Connection Type | National Pipe Thread (NPT) |
| Dial | Aluminum, white background, dual scale, black Celsius scale and black Fahrenheit scale |
| Gauge Fill Fluids | Dry Gauge |
| Lens/Display Material | Acrylic |
| Mounting Options | Chrome Front Flange |
| Note | Only available on 300 SeriesNot available for gauge sizes >=4" or >=16` capillaryThermowells are recommended for pressure, corrosive fluids and high velocity applications. |
| Operating Temperature [Max] | 240 |
| Operating Temperature [Min] | 30 |
| Options and Accessories | Brass, Stainless Steel, or Phenolic caseDry or liquid filledBottom, back or lower back connectedMounting options: front or rear flange, bezel, and u-clampCapillary material: Copper or Stainless Steel |
| Pointer | Aluminum, Black Finish |
| Price: | $438.44 |
| SchemaID | 102551 |
| Series | 300 |
| Syndication, Unit | 1 |
| Thermowells | Thermowells allow a temperature instrument to be removed and replaced without shutting down and draining the process, and reduce the possibility of damage to the temperature instrument. |
| Type | Remote Dial Indicating Thermometer |
