<p>Offering accuracy and repeatability in essential weighing applications in laboratory, industrial and education settings, PR Analytical and Precision Balances deliver competitive performance at an economical price. Featuring RS232 connectivity for easy communication, and a backlit display and a simple interface for uncomplicated operation, the PR is perfectly designed for your workplace. </p> <p><strong>Applications </strong> </p> <p>Basic Weighing, Parts Counting, Percent Weighing </p> <p><strong>Display </strong> </p> <p>Backlit Liquid Crystal Display (LCD) </p> <p><strong>Operation </strong> </p> <p>AC adapter (included) </p> <p><strong>Communication </strong> </p> <p>RS232 (one port included) </p> <p><strong>Construction </strong> </p> <p>ABS top housing, removable stainless steel pan, removable glass draftshield with sliding top door, integrated weigh-below-hook, security bracket, calibration lock </p> <p><strong>Design Features </strong> </p> <p>User-selectable environmental filters and brightness settings, auto-tare, auto-dim, user-selectable span calibration points, software lockout and reset menu, userselectable communication settings and data print options, user-definable project and user IDs, software overload/underload indicator, stability indicator </p>
Weight:
16.0
Weight:
16.0 LB
Preferred Price:
9.21
Price:
9.21
Min Simple Price:
1.57495
Absolute Min Price:
8.36
Min Price:
8.36
Dimensions:
[13.0, 11.0, 6.0]
qty:
21
simpleSku:
MzEwOA:::30452494
sku:
MzEwOA::NX:30452494@y0
condition:
11
seller:
dscbalances.com
amzMan:
ohaus
HazMat:
False
DropShip:
True
Attributes
| Key | Value |
|---|---|
| Approvals | CSA, UL, IEC, FCC, ICES, IEC |
| Auto-Door, In-use cover | No |
| Auxiliary Display Model | Available as an Accessory |
| Battery Life | Not Applicable |
| Brand | OHAUS |
| Calibration | Internal, Semi-automatic Internal |
| Calibration Weight Recommended | 500 g OIML F1 or ASTM Class 4 |
| capacity | 520.000000 |
| Capacity, Maximum Capacity | 520 g |
| capacity-g | 520 |
| Certified Readability, Readability (Certified) | 0.01 g |
| Class | II |
| Communication | RS232 |
| Construction | Plastic housing, stainless steel pan |
| Dimensions | 11.9 in x 12.5 in x 7.9 in (303 mm x 317 mm x 201 mm) (HxLxW) |
| Dimensions (H x W x D) | 11.9 x 7.9 x 12.5 |
| Display | LCD with backlight, Easy-to-read, bright backlit display and a simple user interface |
| Display Type | Backlit LCD |
| Draft Shield | 6.8 x 5.1 x 8.1 in |
| Draft Shield, Draftshield | Included |
| Housing | ABS top housing, removable stainless steel pan |
| Interface | RS232, USB Device, Ethernet |
| Internal Calibration | InCal? - Semi Automatic |
| Legal for Trade, legal-for-trade | NTEP Certified |
| Linearity | 0.002 g, ?0.002 |
| list-price | 1970.00 |
| Manual | PR523N_Manual.pdf |
| manufacturer-part-number, Model, model | PR523N |
| Max Capacity | 520g |
| Minimum Weight | 0.82 g |
| Minimum Weight USP | 2 g |
| Net Weight | 10 lb (4.5 kg) |
| Net Weight, Weight | 10 lb |
| NTEP | Yes |
| Operating Temperature | 50?F to 86?F, 50? F to 86? F / 10? C to 30? C |
| Overall Dimensions (W x D x H) | 7.9 x 12.5 x 11.9 in |
| Pan Construction | Stainless Steel |
| Pan Size | 4.7 in, 4.7 in (120 mm), 4.72 in. / 120 mm |
| pan-size | 4.72 / 120 |
| Power | AC adapter, AC Adapter (Included) |
| Power Supply | Power input: 100?240V ~ 200mA 50?60Hz 12?18VA, Power output: 12 VDC 0.5A |
| Readability, Repeatability | 0.001g |
| Readability, Repeatability (Std Dev) | 0.001 g |
| readability-certified | 0.01 |
| readability-g, repeatability | 0.001 |
| Spec Sheet | PR523N_Spec_Sheet.pdf |
| Stabilization Time | 2 s, 2 seconds |
| Tare Range | To capacity by subtraction |
| Units of Measurement | Milligram; Gram; Ounce; Carat; Ounce Troy; Grain |
| Weighing Units | g, mg, ct, dwt, grain, oz, ozt |
| Working Environment | 50?F ? 86?F, 80%RH, non-condensing; 50?F ? 104?F, 80%RH, non-condensing (10?C ? 30?C, 80%RH, non-condensing; 10?C ? 40?C, 80%RH, non-condensing) |
