- mpn1136500
- brandname: OSG
- manufacturername: OSG
Straight Fluted Tap, Bot, HSS, 1 In-12, H4
- Brand: OSG
- PartNumber: 1136500
- Model: 1136500
- PackageQuantity: 1
- Binding: Misc.
- Manufacturer: OSG Tap And Die
- Label: OSG Tap And Die
Attributes
| Key | Value |
|---|
| 55% Thread Drill Size | 15/16", 15/16 in |
| 65% Thread Drill Size | 23.60mm, 23.60 mm |
| 75% Thread Drill Size | 23.30 mm, 23.30mm |
| Brand | Osg |
| Coolant Fed | Non-Coolant Through |
| Current Stock | 9 |
| Extended Neck | Yes |
| International Shipping | No |
| Item | Tap, Straight Flute Han. |
| Lead Time | Expected to ship in 1-2. |
| List Number | 101 |
| Material | High Speed Steel |
| Measurement System | Fractional Inch |
| Mpn | 1136500 |
| Number of Flutes | 4 |
| Overall Length | 5 1/8 in, 5-1/8" |
| Pitch Diameter Limit | H4 |
| Primary Material Applic. | All Materials |
| Primary Material Applic. | H, K, M, N, O, P, S |
| Prop 65 | WARNING: Cancer and Rep. |
| Secondary Material Appl. | Aluminum, Brass, Bronze. |
| Secondary Material Appl. | K, N, P |
| Series | 101 |
| Shank Dia. | 0.800" |
| Shank Length | 2 3/8 in, 2.4000" |
| Shank Type - Machining | Straight |
| SKU | ZO-G1643607 |
| Spiral Direction | Neutral |
| Square Size | 0.6000 in, 0.6000" |
| Standards | ANSI |
| SubCategory | Machining/Threading |
| Tap Chamfer | Bottoming |
| Tap Dimension Type | Inch |
| Tap Finish | Bright |
| Tap Grouping | Tap |
| Tap Length Standard | ANSI |
| Tap Material | High Speed Steel |
| Tap Shank Standard | ANSI |
| Tap Size | 1" |
| Tap Style | Straight Flute (Hand) |
| Tap Thread Size | 1"-12 |
| Tap Thread Type | UNF |
| Thread Direction | Right Hand |
| Thread Length | 2-1/2" |
| Thread Limit | H4 |
| Thread Limit / Class of. | H4 |
| Thread Size | 1"-12 |
| Thread Standard | UNF |
| Threads per Inch | 12 TPI |
All Prices
| Img | Seller | Supplier SKU | Min Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|
 | Zoro | G1643607 | 84.99 | 1 | 24 | | Osg | 0.65 | 84.99 @ 1 |
 | simsupply.com | ZO-G1643607 | 100.69 | 1 | 9 | | Osg | | 100.69 @ 1 |
 | sustainablesupply.com | C1476743 | 114.45 | 1 | In Stock | | OSG | 0.62 | 114.45 @ 1 |
 | National Supply Network | 65254112 | 121.5 | 1 | In Stock | | OSG | | 121.5 @ 1 |
 | bscsource.com | 1136500 | 130.79 | 1 | In Stock | | OSG | | 130.79 @ 1 |
| grainger.ca | OSG1136500 | 142.9112014 | 1 | In Stock | | OSG | 0.62 | 142.9112014 @ 1 |
