mpn:
brand:
manufacturer:
MPN:
Weight:
0.858
Weight:
0.858 LB
Price:
2.69
qty:
128
simpleSku:
OTExMQ:::LCDX8-14A-L
sku:
OTExMQ::4I:LCDX8-14A-L@y0
condition:
11
seller:
cbtcompany.com
amzMan:
panduit
Dimensions:
[2.0, 1.0, 1.0]
Attributes
| Key | Value |
|---|---|
| Allowable Gauge Range | 8 |
| Approvals | CSA, UL |
| Base Product Number | LCDX |
| Brand | Pan-Lug? |
| Category | Connectors, Interconnects |
| Color | Red |
| Color Code | Red |
| Color Family | Red |
| Contact Finish | Electro-Tin |
| Contact Material | Copper |
| Country of Origin | MX - Mexico |
| Country of Origin (subject to change) | Mexico |
| Diameter - Barrel ID | 0.180" (4.57mm) |
| Diameter - Barrel OD | 0.270" (6.86mm) |
| Diameter - Ring ID | 0.270" (6.86mm) |
| Die Color | Red |
| ECCN | EAR99 |
| Family Series | Panduit Terminals, Pan-Lug Compression Series |
| Features | - |
| Finish | Tin-Plated |
| Gross Weight | 0.87 lbs |
| Hole Center to Center | 44565 |
| Insulation | Non-Insulated |
| Item Number | LCDX8-14A-L |
| Length - Overall | 1.830" (46.48mm) |
| Lug Wire Size | 8 AWG |
| Manufacturer | Panduit |
| Manufacturer Part Number | LCDX8-14A-L |
| Material | Copper |
| Material/Composition | Copper |
| Max Conductor Range | 8 AWG |
| Mfr | Panduit Corp |
| Min Conductor Range | 8 AWG |
| Mounting | 2-Hole |
| Mounting Type | Free Hanging (In-Line) |
| Net Weight | 0 lbs |
| Number of Conductors | 1 |
| Number of Holes | 2 |
| Outer Diameter | 0.27 in. |
| Outside Dia. | 0.27 |
| Overall Length | 1.83 in |
| Package | Bulk |
| Part Status | Active |
| Product Series | Pan-Lug Compression |
| RoHS Compliant | Yes |
| Series | Pan-Lug? |
| Standards | C22.2 No. 65-13, 486A-486B File #E52164 |
| Stud Hole Spacing | 0.63 in. |
| Stud Size | 1/4 in |
| Stud/Tab Size | 1/4 Stud |
| Tab Thickness | 0.070" (1.78mm) |
| Terminal Style | Two Stud Holes |
| Terminal Type | Lug, Grounding |
| Termination | Crimp, Barrel |
| Tool Type | Tin-Plated Copper Compression Connectors - Lugs |
| UNSPSC | 39121405 |
| Width - Outer Edges | 0.480" (12.19mm) |
| Wire Gauge | 8 AWG |
All Prices
| Img | Seller | Supplier SKU | Requested Price | Calc MOQ Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|---|---|---|---|---|---|---|---|---|---|
 | cbtcompany.com | LCDX8-14A-L | 2.69 | 2.69 | 1 | 37 | PANDUIT | 2.69 @ Qty: 1+ | ||
 | French Gerleman | PANDLCDX814AL | 3.14 | 3.14 | 1 | 37 | Panduit | 3.14 @ Qty: 1+ | ||
 | alldataresource.com | LCDX8-14A-L | 4.0 | 4.0 | 1 | 37 | Panduit | 4.0 @ Qty: 1+ | ||
| Digi-Key | 1762151 | 4.58 | 1834.748 | 1000 | 128 | Panduit Corp | 4.58 @ Qty: 1+ | |||
 | Newark | 52AH0944 | 5.17 | 5.17 | 1 | In Stock | PANDUIT | 5.17 @ Qty: 1+ | ||
| Onlinecomponents.com | LCDX8-14A-L | 5.33 | 5.33 | 1 | 37 | Panduit | 5.33 @ Qty: 1+ | |||
 | Zoro | G504858623 | 5.81 | 8.134 | 2 | 37 | 58 | Panduit | 5.81 @ Qty: 2+ | |
 | Galco | LCDX8-14A-L-PNDT | 5.99 | 123.394 | 50 | In Stock | Panduit | 0.87 | 5.99 @ Qty: 50+ | |
 | Platt.com | 0613228 | 6.37 | 6.37 | 1 | 37 | Panduit | 6.37 @ Qty: 1+ | ||
| Airline Hydraulics | PANDUIT LCDX8-14A-L | 7.21 | 7.21 | 1 | 37 | Panduit Corp | 7.21 @ Qty: 1+ | |||
| us.rs-online.com | 72051925 | 7.85 | 161.71 | 50 | 37 | Panduit | 7.85 @ Qty: 50+ | |||
 | gordonelectricsupply.com | LCDX8-14A-L | 315.0 | 315.0 | 1 | 37 | 12 | PANDUIT | 315.0 @ Qty: 1+ | |
 | jensentools.com | 10016443 | 328.93 | 328.93 | 1 | In Stock | Panduit | 328.93 @ Qty: 1+ | ||
 | turtle.com | PAN LCDX8-14A-L | 705.43 | 705.43 | 1 | 37 | Panduit | 705.43 @ Qty: 1+ | ||
| Graybar | 25045005 | 781.8496 | 781.8496 | 1 | 118 | Panduit | 781.8496 @ Qty: 1+ |
