| Application | For heavy duty such as securing conduit or large cable bundles to permanent structures and indoor and outdoor use, General |
| Approximate Length, Nominal Length | 34 " |
| Base Product Number | PLT10E |
| Brand, Manufacturer | Panduit |
| Bundle Diameter | 10 in., 10.00" (254.00mm) |
| Catalog Number, Item Number, Manufacturer Part Number | PLT10EH-Q0 |
| Category | Cables, Wires - Management |
| Color, Color Family, Colour | Black |
| Country of Origin | SG - Singapore |
| Country of Origin, Country of Origin (subject to change) | Singapore |
| Diameter Range | 10 in |
| Duty Rating, Size | Extra-Heavy |
| ECCN | EAR99 |
| Family / Style, Sub Brand | Pan-Ty? |
| Family Series | Panduit Cable Ties, Pan-Ty Lashing Ties Series |
| Features, Type | Weather Resistant |
| Gross Weight | 1.85 lbs |
| Heat Stabilized, Made in USA, Plenum Rated | No |
| Height | 0.4" (10.2mm) (Head) |
| Height (in), Thickness (in) | 0.08 " |
| Item Type | Cable Ties |
| Length | 34.2 in., 869mm, 34.2, 34.2" (868.68mm), 34.200 in |
| Length (In) | 34.2 " |
| Length - Actual | 2.850' (868.68mm) |
| Length - Approximate | 34.25" |
| Lock Mechanism | Locking |
| Material | Nylon 6/6, Weather Resistant Nylon 6.6, Nylon, Polyamide (PA66), Nylon 6/6, Nylon 66 |
| Max Bundle Diam. (in) | 10 " |
| Maximum Bundle Diameter | 254mm |
| Maximum Operating Temperature | +85?C |
| Mfr | Panduit Corp |
| Mounting Type | Free Hanging (In-Line) |
| Net Weight | 0 lbs |
| Package | Bulk |
| Product Header | Extra-Heavy Cross Section Cable Tie |
| Product Series | Pan-Ty Lashing Ties |
| Product Status | Active |
| Product Thickness | 0.085 in |
| Protection Class | Tie, Cable |
| Quantity | 25 |
| Series | PAN-TY PLT Series, PAN-TY? PLT, PLT |
| Shelf Life, Shelf Life Start, Storage/Refrigeration Temperature | - |
| Special Features | Indoor/Outdoor, Locking, Weather Resistant |
| Standard | UL 62275 Compliant (Type 1, 11), UL Recognized (File #E56854), CSA Certified, RoHS Complaint |
| Tensile Strength | 250 lbs (113.40 kg), 250, 250 lb., 250 lbs., 1112N |
| Tensile Strength (lb), Weight Capacity | 250 lbs |
| Thickness | 0.09 |
| Type | Lashing Cable Tie, General Purpose |
| UNSPSC | 39121703 |
| UPC, UPC Code | 074983542505 |
| UV Resistant, Weather Resistant | Yes |
| Width | 0.8, 0.500" (12.70mm), 0.500 in, 12.7 mm, 0.5" (12.7mm) |
| Width (in) | 0.5 " |
| Wire/Cable Tie Type | Lashing, Locking |
