| accessory type | Panduit?? |
| Allowable Gauge Range | 4 - 1/0 |
| Also Known As... | Bug |
| Application | Panduit??? |
| Approvals | CSA, UL |
| Brand | PANDUIT, Pan-Lug? |
| Carton | 50 |
| Category Description | Split Bolts |
| Classification | Split Bolts |
| Color | SE |
| Composition | Copper |
| Cond. Equal Main/Tap | 4 str.-1/0 str. |
| Cond. Max Main/Min Tap | 14 str. |
| Conductor Material | Copper |
| Country of Origin | BR - Brazil |
| Country of Origin (subject to change) | Brazil |
| Description | SPLT Bolt Conn |
| ECCN | EAR99 |
| extra long description | PAN SBC1/0-L Pan-Lug SBC1/0-L Mech |
| Family Series | Panduit Connectors, Pan-Lug Mechanical Series |
| Finish | blank |
| for use with | Copper Code Conductors |
| Gross Weight | 7.7 lbs |
| GTIN | 00074983627257 |
| Height | 1.55 in. |
| Insulated/Non-Insulated | Non-Insulated |
| Item | Mechanical Connector,4 AWG-1/0 AWG |
| Item Number | SBC1/0-L |
| Long Description | Split Bolt Connector, #4 AWG (Stranded) Conductor Size, #1/0 AWG (Stranded) Conductor Size, Non-Insulated, Copper Conductor Material, 1.55 in Overall Length, 1 lb/EA |
| Manufacturer | PANDUIT |
| Manufacturer Part Number | SBC1/0-L |
| Manufacturers Part Number | SBC10L |
| Material | Copper |
| Maximum Conductor Size | #1/0 AWG (Stranded) |
| media | Yes |
| Minimum Conductor Size | #4 AWG (Stranded) |
| Net Weight | 0 lbs |
| Overall Length | 1.55 in;39.4 mm |
| package quantity | 50 PK |
| Product Series | Pan-Lug Mechanical |
| Product Type | Split Bolt Connector |
| Rated Voltage | 600V |
| RoHS | Yes |
| Short Description | Split Bolt Connector, Non-Insulated, 1.55 in;39.4 mm |
| similar brands | Servit? |
| standard | UL listed to 467 and 486 and CSA certified for use up to 600V & Temperature Rated to 90?C |
| Standards Met | RoHS Compliant;CSA Certified C22.2 No. 65-13;UL Listed |
| Style | Split Bolt |
| sub brand | Type Sbc |
| Tap Conductor Size | 14 AWG |
| Type | Mechanical Connectors - Split Bolt |
| UNSPSC | 39121408 - Mechanical connectors, 39121408 |
| UPC | 074983627257 |
| UPC Code | 074983627257 |
| Voltage Rating | 600 |
| Weight | 1 lb/EA |
| Weight per each | 1 |
