Parker 159F-6-6

mpn159F-6-6
brandname: PARKER
manufacturername: PARKER

3/8" Flare x MNPT Brass 90 Degree Elbow

3/8" Flare x MNPT Brass 90 Degree Elbow

zoom

Brand: Parker
PartNumber: 159F-6-6
Model: 159F-6-6
PackageQuantity: 1
Manufacturer: PARKER
Label: PARKER

Attributes

Key	Value
Application	Natural Gases, LP Gases
Basic Pipe Fitting Mate.	Metal
Basic Pipe Fitting Shape	Elbow
Body Shape	Extruded
Compatible Tube Material	Aluminum, Brass, Copper.
Configuration Sub-Type	Male Elbow 45?
Connection Type	Flared x MNPT
Country of Origin (subj.	United States
End Connection Type	Flared
Fitting Material	Brass
Fitting Pipe Size	3/8 in
Fitting Shape	Elbow
Fitting Side A Connecti.	Flared
Fitting Side A Tube Out.	3/8 in
Fitting Side B Connecti.	MNPT
Fitting Side B Pipe Size	3/8 in
Fitting Thread Size	5/8-18
Flare Angle	45 Degrees
Flare Thread Size	5/8-18
Flare Type	45 Degrees
For Tube OD	3/8 in
For Tube Outside Diamet.	3/8 in
Inch/Metric	Inch
Item	90 Degree Male Elbow
Material	Brass
Max. Pressure	450 to 2800 psi
Maximum Operating Press.	1,000 psi
Maximum Operating Tempe.	250 Degrees F
Minimum Operating Tempe.	-65 Degrees F
O-Ring Material	Fluorocarbon
Outer Diameter 1	3/8 Inch
Overall Length	29/32 in
Parker Group	Fluid Connector
Pipe Fitting Connection.	Flare x MNPT
Pipe Size	3/8 in
Pipe Size (Fittings)	3/8"
Pipe Size - Pipe Fitting	3/8 in
Pressure Rating	1000 PSI
SAE Compliance	J512 and J513
Specific Fitting Shape	45 Degrees Forged Elbo.
Specific Pipe Fitting S.	90 Degree Elbow
Standards	SAE J512, SAE J513
Temp. Range	-65 Degrees To 250 Deg.
Thread 1 Type	UN/UNF
Tube Fitting Material	Brass
Tube Size	3/8 in
UOM	EACH

All Prices

Img	Seller	Supplier SKU	Min Price	MOQ	In Stock	Lead Time	Brand	Weight	Preferred Tier
	AmazonSC	B008FMSTRG	10.77	1	In Stock		Parker Hannifin		10.77 @ 1
	bscsource.com	159F66	11.59	1	In Stock		Parker		11.59 @ 1
	MRO Stop	271013342	13.45	1	In Stock		Parker		13.45 @ 1
	Guardian	62251996	14.31	1	In Stock		Parker		14.31 @ 1
	Wilson	159F-6-6	16.35	1	In Stock		Parker - Fluid System Connectors Division		16.35 @ 1
	Airline Hydraulics	PARKER 159F-6-6	17.59	1	In Stock		Parker		17.59 @ 1
	Radwell	159F-6-6	26.0	10	In Stock		PARKER HANNIFIN		26.0 @ 10
	National Supply Network	62251996	27.81	1	In Stock		Parker		27.81 @ 1
	Zoro	G1250401	38.89	1	53		Parker	1.07	38.89 @ 1
	sustainablesupply.com	C1939592	41.76	1	In Stock		Parker	1.07	41.76 @ 1
	Grainger	1VED2	66.25	1	22	0	PARKER		66.25 @ 1
	Raptor Supplies	AB3UDN	101.0196135	1	In Stock		PARKER		101.0196135 @ 1
