Parker 2.50DSRM04.00

B074JFJGB9

Parker 2.50DSRM04.00 2-1/2" Bore Diameter with 4" Stroke Stainless Steel, Nose Mounted Air Cylinder

Parker 2.50DSRM04.00 2-1/2" Bore Diameter with 4" Stroke Stainless Steel, Nose Mounted Air Cylinderzoom

Attributes

Key Value
:N/A
Air Cylinder Bore Dia.2 1/2 in
Air Cylinder MountNose
Air Cylinder TypeRound Body
Body Material304 stainless steel
Bore Dia.2 1/2 in
Country of Origin (subj.United States
Cushion TypeNone
Cylinder ActionDouble Acting
Cylinder TypeRound Non-Repairable
Dimension A22/25 in
Dimension B1.50 in
Dimension C0.38 in
Dimension Cc0.625 in
Dimension D0.50 in
Dimension E1.75 in
Dimension J0.31 in
Dimension Kk1/2"-20 UNF
Dimension N11 3/8"-12
End Cap MaterialAluminum
FeaturesSwitch Ready
FinishSilver
ItemAir Cylinder
Magnetic PistonYes
Max. Pressure250 psi
MountNose
Nose Mount Thread1 3/8"-12
Overall Length9.6 in
Piston MaterialAluminum
Piston Rod MaterialChrome Plated Steel
Port Size1/4 in FNPT
Rod Dia.0.625 in
Rod Thread Length0.88 in
Rod Thread Size1/2-20 UNF
Single Acting/Double Ac.Double Acting
Stroke4 in
StyleMale
Temp. Range14 Degrees to 140 Degr.
Tube MaterialStainless Steel

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomZoroG6105364103.51In Stock26Parker2.7103.5 @ 1
thumbzoomWilson2.50DSRM04.00132.721In StockParker - Pneumatic Division132.72 @ 1
thumbzoomsustainablesupply.comC1685468169.921In StockParker2.7169.92 @ 1
thumbzoombscsource.com250DSRM0400177.691In StockParker177.69 @ 1
thumbzoomNational Supply Network85495299194.041In StockParker194.04 @ 1
thumbzoomprimebuy.com2.50DSRM04.00247.41In StockParker247.4 @ 1
thumbzoomGuardian85495299250.211In StockParker250.21 @ 1
thumbzoomRaptor SuppliesAJ2EPC265.4600131In StockPARKER265.460013 @ 1
