| Amperage | 20 A |
| Application Sector | Commercial |
| Color | Ivory |
| Connection | Back and side wire |
| Country of Origin | MX |
| Dielectric Strength | Withstands 2000V minimum |
| Environmental Conditions : Flammability | UL94 V2 |
| NEMA Rating | 5-20R |
| Number of Poles | Double Pole |
| Number of Wires | 3.0 |
| Product Line | Pass & Seymour |
| Special Features | Heavy-duty, brass strap for added strength and ground conductivity. .032 inch thick, brass, triple-wipe power contacts for lasting retention. Strap tabs wrap around face to prevent strap from separating from face and back body. Easily accessed break-off, line-contact connecting tab for fast, easy split-circuit wiring. High strength nylon face. Internal screw-pressure-plate back and side wired to accept #14 ? #10 AWG stranded or solid copper or copper-clad conductors. Eight back wire holes. Auto-ground clip assures positive ground. |
| Standard | cULus UL498, CSA C22.2 No. 42 |
| Temperature Rating : Temperature Rise: Maximum 30?C temperature rise at full-rated current after 50 cycles of overload at 150% of rated current with direct current. Operating Temperature | Maximum continuous +60?C, minimum -40?C without impact |
| Voltage | 125.0 V |
| Wire Size | #14 - #10 |
