mpn:
brand:
manufacturer:
MPN:
Description:
Shop Pfannenberg 11622804050 and trust MRO to be your reliable Pfannenberg supplier to experience the difference that quality and expertise can make. Trusted since 1898. Fast, Free Shipping.
Weight:
0.4
Weight:
0.4 LB
Preferred Price:
301.79
Price:
301.79
Min Simple Price:
170.6
Absolute Min Price:
242.08
Min Price:
242.08
Dimensions:
[72.0, 72.0, 72.0]
qty:
21
simpleSku:
MDkzNA:::11622804050
sku:
MDkzNA::S3:11622804050@y0
condition:
11
seller:
Megadepot
amzMan:
pfannenberg
HazMat:
False
DropShip:
True
Attributes
| Key ^ | Value |
|---|---|
| Air Flow w/Filter, Airflow with Filter, Fan Exhaust Airflow | 28 CFM |
| Air Flow, Unimpeded Airflow | 38 CFM |
| Airflow Direction | In or Out |
| Airflow Monitor, RoHS | No |
| Approvals | UL, cUL, CE, (on request: GOST), UL, cUL, CE, CE, cUL, UL |
| Bearing Type | Ball |
| Bearing Type, Type | Ball bearing |
| Bezel Color, Color | Black |
| Capacity | 38 CFM2 |
| Certification Listings | UL;cUL;CE |
| Color | RAL 9011 (Black) |
| Connection | Cable, 2-core 310 mm, Cable;2-Core;Length 310 mm |
| Connection Type | Wire Leads, Cable, 2-core, length 310 mm |
| Current Rating | 0.21 A |
| Cut Out Dimensions | 4.92 x 4.92 |
| Cut-Out Dimensions | 125 x 125 mm |
| Cutout Dimensions | 4.92 x 4.92" |
| dBa | 44 |
| Depth (In) | 2.76 |
| Design (housing and protection against accidental contact) | Self-extinguishing, UL 94 VO injection-molded thermoplastic |
| Dimensions (W x H x D) | 5.71 x 5.71 x 2.76" |
| Dimensions W x H x D (in) | 5.71 x 5.71 x 2.76 in |
| Enclosure | NEMA 12 |
| Enclosure Cut-Out (in) | 4.92 x 4.92 " |
| Estimated Weight | 0.97 |
| Family Series | Pfannenberg Fans, PF22000 Series |
| Filter Mat Quality Class | G4 |
| Filtration Efficiency/Mat Quality Class | 91% / G 4 |
| Frame Remarks | - |
| Frequency | DC |
| Gross Weight | 1.055 lbs |
| Height (In), Width (In) | 5.71 |
| IP Rating | IP55 |
| Item Condition | Factory New |
| Item Number, Manufacturer Part Number, Part Number | 11622804050 |
| Manufacturer | Pfannenberg |
| Material | Injection-Molded Thermoplastic |
| Model | PF 22000 |
| Mount Type | Side |
| Mounting | Side Mount |
| Mounting Depth | 2.52 " |
| Nema Rating | Type 12 |
| Net Weight, Weight | 0.97 lbs |
| Noise Level | 44 dB (A), 44 dB, 44 dB(A) |
| Nominal Size | 5 " |
| Nominal Voltage, Operating Voltage, Rated Voltage, Voltage, Voltages ? 10% | 24 VDC |
| Operating Temp Range (F) | 5-131 ?F |
| Power Consumption | 5 W |
| Power Consumption (W), Watts | 5 |
| Product Series | PF22000 |
| Service Life | 62500 h |
| Service Life, Service Life L10 (+ 40 ?C) | 62,500 h |
| System of Protection | IP 55 / NEMA Type 12 (fluted filter) |
| System of Protection (EN 60529) | IP 55 |
| System of protection (UL 50) | NEMA Type 12 - fluted filter |
| Voltage Tolerance | +/- 10% |
| Volts | 24 DC |
| Weight | 0.97 lb |
All Prices
| Img | Seller | Supplier SKU | Requested Price ^ | Calc MOQ Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|---|---|---|---|---|---|---|---|---|---|
 | Megadepot | 11622804050 | 170.6 | 170.6 | 1 | In Stock | Pfannenberg | 0.97 | 170.6 @ Qty: 1+ | |
 | Solutions Direct | 11622804050 | 181.26 | 181.26 | 1 | In Stock | Pfannenberg | 0.97 | 181.26 @ Qty: 1+ | |
 | usmegastore.com | 11622804050 | 201.75 | 201.75 | 1 | In Stock | Pfannenberg | 0.97 | 201.75 @ Qty: 1+ | |
 | Galco | 11622804050-PFNG | 201.75 | 201.75 | 1 | 6 | Pfannenberg | 1.055 | 201.75 @ Qty: 1+ | |
 | motorsandcontrol.com | 11622804050 | 210.15 | 210.15 | 1 | In Stock | Pfannenberg | 0.97 | 210.15 @ Qty: 1+ | |
 | Dealers Electric | 11622804050 | 229.03 | 229.03 | 1 | In Stock | Pfannenberg | 2.0 | 229.03 @ Qty: 1+ | |
 | MRO Supply | 2487034 | 269.0 | 269.0 | 1 | In Stock | Pfannenberg | 269.0 @ Qty: 1+ |
