1984992

mpn1984992
brandname: Phoenix Contact
manufacturername: Phoenix Contact

Fixed Terminal Blocks Ptsa 1.5/5-3.5-F

Fixed Terminal Blocks Ptsa 1.5/5-3.5-F

zoom

PartNumber: 1984992
PackageQuantity: 1
Manufacturer: Phoenix Contact
Label: Phoenix Contact

Attributes

Key	Value
Agency Approvals	UL ; cULus ; VDE, UL, c.
Alternate Mfr Part Numb.	PTSA 1 5/ 5-3 5-F
Approvals	UL Recognized, VDE Guta.
Category	Connectors, Interconnec.
Clamp Material - Plating	-
Color	Green
Contact Material - Plat.	-
Current	2 A
Current Rating	2 A, 8 A
Diameter, Hole	1 mm
Dimensions	12mm L x 14mm + 3.5mm W.
Dimensions, Pin	0.4 x 0.75 mm
Family Name	COMBI Plug Family
Features	-
Hole Diameter	1 mm
Housing Material	Polyamide (PA), Nylon
Insulation Material	PA
Level	Single Level
Material, Insulation	PA
Mating Orientation	45? (135?) Angle with B.
Mfr	Phoenix Contact
Mounting Type	Through Hole, PCB Mount
Number of Contacts	5
Number of Levels	1, 1 Level
Number of Positions	5, 5 Position
Operating Force	PA
Operating Temperature	-
Package	Bulk
Pin Dimensions	0.4 x 0.75 mm
Pin Spacing	3.5 mm (0.138 in), 3.5 .
Pitch	0.138" (3.50mm), 3.5 mm
Positions Per Level	5
Primary Type	Wire to Board
Product Status	Active
Screw Material - Plating	-
Screw Thread	-
Series	COMBICON PTSA, COMBICON.
Special Features	Compact
Stripping Length	8 mm
Surge Voltage	2.5 kV (III/3, III/2, I.
Termination	Through Hole, Push-In
Torque - Screw	-
Type	Terminal, Fixed
UPC Code	4017918922078
Voltage	300 V
Voltage Rating	200 V, 250 V
Voltage, Surge	2.5 kV (III???3, III???.
Wire Entry	45?, 45??
Wire Gauge	16-24 AWG
Wire Size	16 AWG, 16-20 AWG
Wire Termination	Screwless - Spring Cage.
Wire Termination Type	Spring Cage, Push-In

All Prices

Img	Seller	Supplier SKU	Min Price	MOQ	In Stock	Lead Time	Brand	Weight	Preferred Tier
	Onlinecomponents.com	1984992	0.495	1	50		Phoenix Contact		0.495 @ 50
	Hotenda	H1618237	0.5458	1	167		Phoenix Contact		0.5458 @ 50
	Radwell	1984992	0.64	1	50		PHOENIX%20CONTACT		0.64 @ 50
	industrialautomationparts.com	AE-008275	0.7	1	50		Phoenix Contact		0.7 @ 50
	Airline Hydraulics	PHOENIX 1984992	0.77	1	50		Phoenix Contact		0.77 @ 50
	us.rs-online.com	70055083	0.81	180	50		Phoenix Contact		0.81 @ 180
	RS Delivers	648-2464	0.828	1	50		Phoenix Contact		0.828 @ 50
	MRO Stop	753020396	0.87	1	50		Phoenix Contact		0.87 @ 50
	Digi-Key	3597012	0.8976	1	50	61	Phoenix Contact		0.8976 @ 50
	electricautomationnetwork.com	PTSA 1,5/ 5-3,5-F	0.96	1	50		PHOENIX_CONTACT		0.96 @ 50
