REOTEMP XR040CF43

B006TLPCCA

REOTEMP XR040CF43 Stainless Steel 3A Sanitary Bi Metal Thermometer, 4" Stem, 3" Dial, 0 to 200 Degrees F, Bottom Mount

REOTEMP XR040CF43 Stainless Steel 3A Sanitary Bi Metal Thermometer, 4" Stem, 3" Dial, 0 to 200 Degrees F, Bottom Mountzoom

Attributes

Key Value
3-A CertifiedYes
Accuracy+/-1%
AdjustmentsExternal
CaseHermetically Sealed
Case MaterialStainless Steel
Coil FinishSilicone Fillable for V.
Connection LocationBottom
Connection Size1-1/2 in Sanitary
Construction300 Stainless Steel Hou.
Country of Origin (subj.United States
Dial Diameter3 in
Dial Size3 in
Enclosure RatingIP67, NEMA 6
Flange Material316 Stainless Steel
Housing Material300 Stainless Steel
Includes NIST-Traceable.No
ItemSanitary Dial Thermomet.
Lens MaterialGlass
Manufacturer Warranty L.5 yr
Manufacturers Warranty .5 yr
Maximum Temperature ?F200 Degrees F
Maximum Temperature F200 Degrees F
Minimum Temperature ?F0 Degrees F
Minimum Temperature F0 Degrees F
Process Connection1 1/2 in Triclamp
Resistance RatingIP67, NEMA 6
ScaleFahrenheit
Scale TypeDial
Sensing ElementBimetal
Standards3-A, ASME B40.3
Stem Dia.1/4 in
Stem Length4 in
Stem Material316 Stainless Steel
Temp. Range (F)0 Degrees to 200 Degre.
Temperature Graduations2 Degrees F
Temperature Range0 Degrees to 200 Degre.
