| Altitude Range | 9,000 ft |
| BtuH | 130000 |
| BtuH - Water Heaters | 130,000 |
| Commercial / Residential, Market, Residential / Commercial | Commercial |
| Compatible Systems and Services | EcoNet |
| Compliance | ASHRAE, CSA, Low Lead Compliant |
| Condensing, Low NOx, Low Nox Burner, WiFi Enabled | Yes |
| Control Type | Digital Display Touchscreen |
| Country of Origin (subject to change) | United States |
| Draft Hood Size | 3 in |
| Environment | Indoor |
| Features | LeakGuard(TM), Integrated BMS Connectivity, Energy and Water Usage Reports, LeakSense(TM), EcoNet(R) Smart Monitoring Technology with Integrated Wifi, Systematic Health Checks, Preventive Maintenance Alerts |
| First Hour Rating | 209 gal |
| First Hour Recovery - Water Heaters | 209 gph |
| Fuel Type, Fuel Type - Water Heaters | Natural Gas |
| Gas Connection | 1/2 in |
| Gas Inlet Size | 3/4 in |
| Green Certification or Other Recognition | ENERGY STAR(R) Certified |
| Height to Cold Inlet, Height to Cold Side Connection | 13 in |
| Height to Gas Connection, Height to Gas Inlet | 70 in |
| Height to Hot Outlet | 57.5 in |
| Height to Hot Side Connection | 57 1/2 in |
| Height to T and P Opening | 57 7/16 in |
| Height to T and P Valve | 57.43 in |
| Height to Top of Heater, Overall Height - Water Heaters | 67 7/8 in |
| Height to Top of Vent Connection | 57.43" |
| Hot Outlet Size, Top Water Connection Size | 1 1/2 in |
| Ignition Type | Direct Spark to Pilot |
| Included Valve Type | Auto Shutoff, Drain, T & P Relief |
| Included Valves | Drain, Shutoff, Temperature and Pressure Relief |
| Item | Commercial Gas Water Heater |
| Item - Water Heaters | Gas Water Heater |
| Jacket Dia. | 26 1/4 in |
| Low NOx Compliant | Includes California Low NOx Compliant Burner |
| Manufacturer Warranty Length | 5 yr Limited Tank |
| Manufacturers Warranty Length | Limited 5 yr Tank and 1 yr Parts |
| Max. Pressure, Maximum Water Pressure | 150 psi |
| Maximum Altitude | 8,999 ft |
| Maximum Delivered Temperature | 185 Degrees F |
| Maximum Heating Capacity | 130,000 BTU/ft/sq ft/hr/ Degrees F |
| Maximum Recovery Flow Rate | 382 gph @ 40 Degrees F |
| Minimum Delivered Temperature | 110 Degrees F |
| Nominal Tank Capacity | 80 gal |
| Operating Voltage | 110V AC |
| Overall Dimensions - Ht. x Dia. | 70.06 in x 26.38 in |
| Overall Height | 70.06 in |
| Recovery @ 100 F Rise | 153 gph |
| Recovery @ 110 F Rise | 139 gph |
| Recovery @ 120 F Rise | 127 gph |
| Recovery @ 130 F Rise | 118 gph |
| Recovery @ 140 F Rise | 109 gph |
| Recovery @ 50 F Rise | 306 gph |
| Recovery @ 70 F Rise | 218 gph |
| Recovery @ 90 F Rise | 170.0 gph |
| Recovery Rate @ Rise | 109 gph @ 140 Degrees F, 118 gph @ 130 Degrees F, 127 gph @ 120 Degrees F, 139 gph @ 110 Degrees F, 153 gph @ 100 Degrees F, 170 gph @ 90 Degrees F, 191 gph @ 80 Degrees F, 218 gph @ 70 Degrees F, 255 gph @ 60 Degrees F, 306 gph @ 50 Degrees F |
| Side Water Connection Size | 2 in |
| Standards | AHRI, ANSI, CSA, LEED |
| Tank Capacity | 80 gal. |
| Tank Capacity - Plumbing | 80.0 gal |
| Tank Capacity - Water Heaters | 80.0 gal. |
| Tank Diameter | 26.38 in |
| Tank Height | 60.5 in |
| Tank Outer Shell Material | Steel |
| Temp. Range | Upto 185 Degrees F |
| Thermal Efficiency | 98 % |
| Uniform Energy Factor | 0.98 |
| Vent Configuration | Direct, Powered |
| Vent Connection Size | 2 in; 3 in; 4 in; 6 in |
| Vent Type | Power Vent or Power Direct Vent |
| Voltage | 120V AC |
| Water Connection Location | Side |
