| Axial Motion | .030 in |
| B1 Shaft Penetration, B2 Shaft Penetration | 1.496 in |
| Bore Dia. | 1.250 in x 0.750 in |
| Bore Tolerance | +0.001 in / -0.000 in |
| Country of Origin (subject to change) | United States |
| Dynamic Torque Non-Reversing | 265 lb-in |
| Dynamic Torque Reversing | 132 lb-in |
| Fastening Dimensions | Metric |
| Length, Overall Length | 3.200 in |
| Material | Anodized Aluminum |
| Max. Angular Misalignment | 2.0 deg |
| Max. Parallel Misalignment (In.) | 0.012 in |
| Max. RPM | 10000 RPM |
| Max. Temp. Range (F) | -40?F to 200?F (-40?C to 93?C) |
| Measurement Type | Inch |
| Number of Screws | 2 ea |
| Outside Dia. | 2.250 in |
| Recommended Shaft Tolerance | +0.000 mm / -0.013 mm |
| Screw Finish | Black Oxide |
| Screw Material | Alloy Steel |
| Screw Seating Torque | 16 Nm |
| Screw Size | M6 |
| Static Torque | 530 lb-in |
| Style | Clamp |
| Torsional Stiffness (Deg./In.-Lbs.) | 1200 lb-in/Deg |
| Weight | 0.720921 lbs |
