| Axial Motion | 0.020 in |
| B1 Shaft Penetration, B2 Shaft Penetration | 1.099 in |
| Bore Dia. | 1.000 in x 0.875 in |
| Bore Tolerance | +0.001 in / -0.000 in |
| Country of Origin (subject to change) | United States |
| Dynamic Torque Non-Reversing | 200 lb-in |
| Dynamic Torque Reversing | 100 lb-in |
| Fastening Dimensions | Metric |
| Keyway (K1) | 1/4 in |
| Keyway (K2) | 3/16 in |
| Length, Overall Length | 2.313 in |
| Material | Anodized Aluminum |
| Max. Angular Misalignment | 2.0 deg |
| Max. Parallel Misalignment (In.) | 0.010 in |
| Max. RPM | 10000 RPM |
| Max. Temp. Range (F) | -40?F to 200?F (-40?C to 93?C) |
| Measurement Type | Inch |
| Number of Screws | 2 ea |
| Outside Dia. | 2.000 in |
| Screw Finish | Black Oxide |
| Screw Material | Alloy Steel |
| Screw Seating Torque | 9.5 Nm |
| Screw Size | M5 |
| Static Torque | 400 lb-in |
| Style | Clamp with Keyway |
| Torsional Stiffness (Deg./In.-Lbs.) | 950 lb-in/Deg |
| Weight | 0.419 lbs |
