| Axial Motion | 0.40 mm |
| B1 Shaft Penetration, B2 Shaft Penetration | 20.4 mm |
| Bore Dia. | 12 mm x 11 mm |
| Bore Tolerance | +0.03 mm / -0.00 mm |
| Country of Origin (subject to change) | United States |
| Dynamic Torque Non-Reversing | 6.80 Nm |
| Dynamic Torque Reversing | 3.40 Nm |
| Fastening Dimensions, Measurement Type | Metric |
| Length, Overall Length | 42.9 mm |
| Material | Anodized Aluminum |
| Max. Angular Misalignment | 1.5 deg |
| Max. Parallel Misalignment (In.) | 0.15 mm |
| Max. RPM | 10000 RPM |
| Max. Temp. Range (F) | -40?F to 200?F (-40?C to 93?C) |
| Number of Screws | 2 ea |
| Outside Dia. | 33.3 mm |
| Screw Finish | Black Oxide |
| Screw Material | Alloy Steel |
| Screw Seating Torque | 2.1 Nm |
| Screw Size | M3 |
| Static Torque | 13.6 Nm |
| Style | Clamp |
| Torsional Stiffness (Deg./In.-Lbs.) | 45 Nm/Deg |
| Weight | 0.1498 lbs |
