| Axial Motion | 0.75 mm |
| B1 Shaft Penetration, B2 Shaft Penetration | 38 mm |
| Bore Dia. | 17 mm x 16 mm |
| Country of Origin (subject to change) | United States |
| Dynamic Torque Non-Reversing | 30.00 Nm |
| Dynamic Torque Reversing | 15.00 Nm |
| Fastening Dimensions, Measurement Type | Metric |
| Keyway (K1), Keyway (K2) | 5 mm |
| Material | Anodized Aluminum |
| Max. Angular Misalignment | 2.0 deg |
| Max. Parallel Misalignment (In.) | 0.30 mm |
| Max. RPM | 10000 RPM |
| Max. Temp. Range (F) | -40?F to 200?F (-40?C to 93?C) |
| Number of Screws | 2 ea |
| Outside Dia. | 57.2 mm |
| Screw Finish | Black Oxide |
| Screw Material | Alloy Steel |
| Screw Seating Torque | 16 Nm |
| Screw Size | M6 |
| Static Torque | 60.00 Nm |
| Style | Clamp with Keyway |
| Torsional Stiffness (Deg./In.-Lbs.) | 135 Nm/Deg |
| Weight | 0.817425 lbs |
