| Bore Dia. | 0.8750 in |
| Bore Tolerance | +0.002 in / +0.0005 in |
| Clearance Dia. | 49.5 mm |
| Country of Origin (subject to change) | United States |
| Dimension Type, System of Measurement | Metric with Inch Bore |
| Material | Anodized Aluminum |
| Number of Screws | 1 ea |
| Operating Temp. Range | -40?F to 200?F (-40?C to 93?C) |
| Outside Dia. | 42 mm |
| Recommended Shaft Tolerance | +0.0000 in / -0.0005 in |
| Screw Finish | Bright, No Plating |
| Screw Location (R) | 16.00 mm |
| Screw Material | 18-8 300 Series Stainless Steel |
| Screw Seating Torque | 9.6 Nm |
| Screw Size | M6 |
| Style | Round |
| Type | One-Piece |
| Weight | 0.0954 lbs |
| Width | 15 mm |
| Width Tolerance | +0.076 mm / -0.254 mm |
