| B1 Shaft Penetration | 22.4 mm |
| Bore Dia. | 13 mm |
| Bore Tolerance | +0.06 mm / +0.02 mm |
| Country of Origin (subject to change) | Germany |
| Fastening Dimensions, Measurement Type | Metric |
| Finish | Clear Anodized |
| Hub Width | 15.0 mm |
| Material | Aluminum |
| Max. RPM | 10000 RPM |
| Max. Temp. Range (F) | -22?F to 175?F (-30?C to 79?C) |
| Number of Screws | 1 ea |
| Outside Dia. | 2.205 in (56.0 mm) |
| Overall Length | 1.772 in (45.0 mm) |
| Recommended Shaft Tolerance | +0.0000 in / -0.0005 in |
| Screw Finish | Black Oxide |
| Screw Material | Alloy Steel |
| Screw Seating Torque | 8.0 Nm |
| Screw Type, Style | Clamp |
| Set Screw Size | M6 |
| Weight | 0.2006 lbs |
