| Axial Motion | 0.70 mm |
| B1 Shaft Penetration, B2 Shaft Penetration | 9.6 mm |
| Bore Dia. | 7 mm x 6 mm |
| Bore Tolerance | +0.020 mm / -0.000 mm |
| Clearance Dia. (mm) | 26.9 mm |
| Country of Origin (subject to change) | Ireland |
| Dynamic Torque Non-Reversing | 2.35 Nm |
| Dynamic Torque Reversing | 1.55 Nm |
| Length, Overall Length | 34.00 mm |
| Material | Anodized Aluminum |
| Max. Angular Misalignment | 3 deg |
| Max. Parallel Misalignment (In.) | 0.40 mm |
| Max. RPM | 5000 RPM |
| Max. Temp. Range (F) | -110?F to 175?F (-78?C to 79?C) |
| Measurement Type | Metric |
| Moment of Inertia | 31.0 g.cm^2 |
| Number of Screws | 2 |
| Outside Dia. | 25 mm |
| Screw Finish | Bright |
| Screw Material | 18-8 300 Series Stainless Steel |
| Screw Seating Torque | 5.40 Nm |
| Screw Size | M3 |
| Style | Clamp |
| Torsional Stiffness (Deg./In.-Lbs.) | 3.9 Nm/Deg |
| Weight | 0.081 lbs |
