B1 Shaft Penetration, B2 Shaft Penetration, Hub Depth | 1.610 in (40.9 mm) |
Bore | 1.0000 in x 22 mm |
Bore Tolerance | +0.0010 in / -0.0000 in (+0.025 mm / -0.000 mm) |
Country of Origin (subject to change) | United States |
Length | 7.750 in (196.9 mm) |
Lubrication | LUBRIPLATE No. 1200-2 |
Matching Boot | UBOOT28/44-NI-KIT |
Material | Alloy Steel |
Max Operating Angle | 90? |
Max. Torque | 13050 in-lb (1474.5 Nm) |
Outside Dia. | 1.745 in (44.3 mm) |
Rated Torque | 2610 in-lb (294.9 Nm) |
SAE or Metric | Inch/Metric |
Style | Round Bore |
Type | Double, Friction Bearing |
Weight | 3.683 lbs |
Yoke Length (LY) | 2.500 in (63.5 mm) |
