| B1 Shaft Penetration, B2 Shaft Penetration, Hub Depth | 1.700 in (43.2 mm) |
| Bore | 25 mm x 0.6250 in |
| Bore Tolerance | +0.0010 in / -0.0000 in (+0.025 mm / -0.000 mm) |
| Country of Origin (subject to change) | United States |
| Keyway | 8 mm x 3/16 in |
| Length | 8.688 in (220.7 mm) |
| Lubrication | LUBRIPLATE No. 1200-2 |
| Matching Boot | UBOOT32/51-NI-KIT |
| Material | Alloy Steel |
| Max Operating Angle | 90? |
| Max. Torque | 19350 in-lb (2186.3 Nm) |
| Outside Dia. | 1.995 in (50.7 mm) |
| Rated Torque | 3870 in-lb (437.3 Nm) |
| SAE or Metric | Inch/Metric |
| Style | Roud Bore, Set Screw, Keyway |
| Type | Double, Friction Bearing |
| Weight | 5.292 lbs |
| Yoke Length (LY) | 2.750 in (69.9 mm) |
