Attributes
| Key ^ | Value |
|---|---|
| B1 Shaft Penetration, B2 Shaft Penetration, Hub Depth | 20.8 mm |
| Bore | 7 mm x 6 mm |
| Bore Tolerance | +0.025 mm / -0.000 mm |
| Country of Origin (subject to change) | United States |
| Length | 57.2 mm |
| Lubrication | LUBRIPLATE No. 1200-2 |
| Matching Boot | UBOOT10/15-NI-KIT |
| Material | Alloy Steel |
| Max Operating Angle | 45? |
| Max. Torque | 76.3 Nm |
| Outside Dia. | 15.7 mm |
| Rated Torque | 15.3 Nm |
| SAE or Metric | Metric |
| Style | Round Bore |
| Type | Single, Friction Bearing |
| Weight | 1.530282 lbs |
| Yoke Length (LY) | 28.6 mm |
