| B1 Shaft Penetration, B2 Shaft Penetration, Hub Depth | 1.030 in (26.2 mm) |
| Country of Origin (subject to change) | United States |
| Length | 3.000 in (76.2 mm) |
| Lubrication | LUBRIPLATE No. 1200-2 |
| Matching Boot | UBOOT14/22-NI-KIT |
| Material | Alloy Steel |
| Max Blind Bore (Inch) | 0.7500 in |
| Max Blind Bore (Metric) | 19 mm |
| Max Operating Angle | 45? |
| Max Round Bore (Inch) | 0.5313 in |
| Max Round Bore (Metric) | 13 mm |
| Max Round Bore With Key (Inch) | 1/2" Bore, 1/8" Keyway |
| Max Round Bore With Key (Metric) | 12mm Bore, 4mm Keyway |
| Max Square or Hex Bore (Inch) | 0.5000 in |
| Max Square or Hex Bore (Metric) | 12 mm |
| Max. Torque | 1750 in-lb (197.7 Nm) |
| Outside Dia. | 0.870 in (22.1 mm) |
| Rated Torque | 350 in-lb (39.5 Nm) |
| SAE or Metric | Inch/Metric |
| Style | Machinable Bore, Assembled |
| Type | Single, Friciton Bearing |
| Weight | 0.356 lbs |
| Yoke Length (LY) | 1.500 in (38.1 mm) |
