Attributes
| Key | Value |
|---|---|
| B1 Shaft Penetration | 30.2 mm |
| B2 Shaft Penetration | 30.2 mm |
| Bore | 11 mm x 11 mm |
| Bore Tolerance | +0.025 mm / -0.000 mm |
| Country of Origin (subject to change) | United States |
| Hub Depth | 30.2 mm |
| Length | 85.9 mm |
| Lubrication | LUBRIPLATE No. 1200-2 |
| Matching Boot | UBOOT16/25-NI-KIT |
| Material | 303 Stainless Steel |
| Max Operating Angle | 45? |
| Max. Torque | 178.0 Nm |
| Outside Dia. | 25.3 mm |
| Rated Torque | 35.6 Nm |
| SAE or Metric | Metric |
| Style | Round Bore |
| Type | Single, Friction Bearing |
| Weight | 0.356 lbs |
| Yoke Length (LY) | 42.9 mm |
