| B1 Shaft Penetration, B2 Shaft Penetration, Hub Depth | 1.700 in (43.2 mm) |
| Bore | 30 mm x 0.7500 in |
| Bore Tolerance | +0.0010 in / -0.0000 in (+0.025 mm / -0.000 mm) |
| Country of Origin (subject to change) | United States |
| Keyway | 8 mm x 3/16 in |
| Length | 5.500 in (139.7 mm) |
| Lubrication | LUBRIPLATE No. 1200-2 |
| Matching Boot | UBOOT32/51-NI-KIT |
| Material | Alloy Steel |
| Max Operating Angle | 45? |
| Max. Torque | 21500 in-lb (2429.2 Nm) |
| Outside Dia. | 1.995 in (50.7 mm) |
| Rated Torque | 4300 in-lb (485.8 Nm) |
| SAE or Metric | Inch/Metric |
| Set Screw Size | 3/8/2016 |
| Setscrew | 3/8-16 |
| Style | Roud Bore, Set Screw, Keyway |
| Type | Single, Friciton Bearing |
| Weight | 3.255 lbs |
| Yoke Length (LY) | 2.750 in (69.9 mm) |
