Ruland MSCC-12-12-F

B01MA27NU1

Ruland - MSCC-12-12-F - Rigid Shaft Coupling: 12 mm Bore Dia, 1215 Lead Free Steel, 29 mm Outside Dia.

Ruland - MSCC-12-12-F - Rigid Shaft Coupling: 12 mm Bore Dia, 1215 Lead Free Steel, 29 mm Outside Dia.zoom

Attributes

Key Value
ApplicationZero Backlash Coupling .
B1 Max Shaft Penetration22.5 mm
B2 Max Shaft Penetration22.5 mm
Bore (B1)12 mm
Bore Dia.12 mm
Bore Tolerance+0.050 mm / +0.012 mm
CategoryHardware, Fasteners, Ac.
Country of OriginUSA
Country of Origin (subj.United States
Description12MMX12MM STEEL RIGID C.
DesignPrecision Honed Bores O.
Digi-Key Part Number3188-MSCC-12-12-F-ND
FinishBlack Oxide
Finish SpecificationHot Process Black Oxide.
Forged Set ScrewM6
Full Bearing Support Re.No
Hex Wrench Size3.0 mm
ItemRigid Shaft Coupling
Item - Rigid Shaft Coup.Rigid Shaft Coupling
Keyway (K1)4 mm
Keyway (K2)4 mm
Keyway Width4 mm
Keyway Width (mm)4
Length (L)45 mm
Machined FromBar Stock
ManufacturerRuland Manufacturing
Manufacturer Product Nu.MSCC-12-12-F
Material1215 Lead Free Steel
Material - Couplings1215 Lead Free Steel
Material Specification1215 Carbon Steel Bar
Max. RPM4,000 RPM
Maximum Speed4,000 RPM
MfrRuland Manufacturing
Moment of Inertia2.327 x 10
Note 1Performance ratings are.
Number of Screws4 ea
Outer Diameter (OD)29 mm
Outside Dia.29 mm
Overall Length45 mm
PackageBag
Precision Honed Bores?Yes
Product StatusActive
ProvidesHigh Torque with No Mis.
Rated TorqueRating Coming Soon
Recommended Shaft Toler.+0.000 mm / -0.013 mm
Screw FinishBlack Oxide
Screw MaterialAlloy Steel
Screw SizeM6
Screw Size (mm)M6
Seating Torque7.2 Nm
Series-
Shaft Locking Type - Co.1 Piece Set Screw
Small Bore (B2)12 mm
Specifications1.142" (29.00mm) Outer .
System of MeasurementMetric
Tariff Code8483.60.8000
Temperature-40?F to 350?F (-40?C t.
TypeRigid Coupling, Set Scr.
UNSPC31163009
UPC634529076521
Weight (lbs)0.413400
With Keyway / Without K.With Keyway
Zero-Backlash?Yes

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
Grainger30VJ2842.81In Stock10RULAND MANUFACTURING42.8 @ 1
thumbzoomRulandMSCC-12-12-F46.571In StockRuland0.413446.57 @ 1
thumbzoomsustainablesupply.comC164584457.971In StockRuland Manufacturing0.4157.97 @ 1
motionindustries.com0480578665.511In StockRuland Manufacturing Co Inc65.51 @ 1
thumbzoomZoroG841386770.11In Stock10Ruland0.4170.1 @ 1
thumbzoomDigi-Key1359942478.57114Ruland Manufacturing78.57 @ 1
thumbzoomRaptor SuppliesAF9WVZ91.45509751In StockRULAND MANUFACTURING91.4550975 @ 1
