mpn:
brand:
manufacturer:
MPN:
Preferred Price:
172.78
Price:
172.78
Min Simple Price:
94.42
Absolute Min Price:
134.07
Min Price:
134.07
qty:
21
simpleSku:
ODkyOQ:::SCB-3003
sku:
ODkyOQ::YS:SCB-3003@y0
condition:
11
seller:
surveillance-video.com
amzMan:
samsung
HazMat:
False
DropShip:
False
Attributes
| Key ^ | Value |
|---|---|
| Auto Gain Control | Off / Low / High |
| Auto Gain Control, Automatic White Balance, Back Light Compensation, Day/Night, Digital Noise Reduction, Illumination, Motion Detection Tracking, On Screen Display Menu, Privacy Masking, Wide Dynamic Range | Yes |
| Automatic White Balance | ATW / Outdoor / Indoor / Manual / AWC (1,700?K ~ 11,000?K) |
| Backlight Compensation | Off / User BLC / HLC / WDR |
| Camera Signal, Type | Analog |
| Connection Type | Wired |
| Country of Origin (subject to change) | China |
| Day/Night Capable | Day/Night |
| Dia. (In.) | 4-7/8 |
| Digital Noise Reduction | SSNRIII (Off / On) |
| Dimensions (W x H) | 73.1 x 67.2 x 123.9mm (2.88" x 2.65" x 4.88") |
| Durability | Indoor |
| Electronic Shutter | 1/60 ~ 1/120,000sec |
| Exposure Conditions | 14 Degrees to +131 Degrees F / Less Than 90% RH |
| Features | Auto Gain Control, Automatic White Balance, Back Light Compensation, Coaxitron, Day/Night, Digital Noise Reduction, Motion Detection Tracking, On Screen Display Menu, Privacy Masking, Wide Dynamic Range |
| Height (In.) | 2-21/32 |
| Image Device | 1/3" Super HAD CCD II |
| Image Pixels Total</th> < | 1,028(H) x 508(V) |
| Image Pixels-Effective</th> < | 976(H) x 494(V) |
| Infrared Distance | Non Infrared |
| Item | Camera |
| Lens | Manual/Auto Iris (Video/DC) |
| Lens Type | Not Included |
| Line Resolution | 700 Color, 700 B/W |
| Manufacturer | Samsung |
| Minimum Scene Illumination | Color : 0.1Lux@F1.2 (50IRE), 0.0002Lux (Sens-up, 512x), B/W : 0.01Lux@F1.2 (50IRE), 0.00002Lux (Sens-up, 512x) |
| Motion Detection | Built-in |
| Mount | Ceiling, Surface |
| Mount Type | Bracket Required |
| Operating Humidity | Less than 90% RH |
| Operating Temperature | -10?C ~ +55?C (+14?F ~ +131?F) |
| OSD Menu | English, Japanese, Spanish, French, Portuguese, Korean |
| Pixels | 1028(H) x 508(V) / 976(H) x 494(V) |
| Power Consumption | 4W, Max. 4W |
| Privacy Zone | Off / On (12 programmable zones with polygonal masking) |
| Promotion Restriction | Not eligible for promotion |
| Protocols | Coax : Pelco-C (Coaxitron), RS-485 : Samsung-T/E, Pelco-D/P, Panasonic, Bosch, Honeywell, Vicon, GE, AD |
| Resolution | 700 TVL |
| S/N Ratio | 52dB (AGC off, Weight on) |
| S/N Ratio (dB) | 52 |
| Scanning | 2:1 Interlace |
| Scanning Horizontal | 15.734KHz |
| Scanning System | 2 : 1 Interlace |
| Scanning Vertical</th> < | 59.94Hz |
| Sensor Option | 1/3" CCD |
| Signal System | NTSC |
| SKU | SCB-3003 |
| Synchronization | Internal / Line lock / External |
| Video Output | CVBS : 1.0 Vp-p / 75? composite |
| Voltage | 24VAC/12VDC, 12vDC, 24vAC, Dual Voltage |
| Width (In.) | 2-7/8 |
| Zoom Ratio | Off / On (1x ~ 16x) |
