SANYO 9GA0424P6F001

B017T1ASO0

9GA0424P6F001, DC Fan Axial Ball Bearing 24V 20.4V to 27.6V 7.4CFM 28dB 40 X 40 X 20mm

9GA0424P6F001, DC Fan Axial Ball Bearing 24V 20.4V to 27.6V 7.4CFM 28dB 40 X 40 X 20mmzoom

Attributes

Key Value
Air Flow7.4 CFM (0.207m?/min)
Approval AgencyCSA, TUV, UL
Base Product Number9GA0424
Bearing TypeBall
CategoryFans, Thermal Management
Current Rating (Amps)0.040A
Fan TypeTubeaxial
FeaturesPWM Control, Speed Sens.
Ingress Protection-
Lifetime @ Temp.60000 Hrs @ 60?C
Material - BladePlastic
Material - FramePlastic
MfrSanyo Denki America Inc.
Noise28.0dB(A)
Operating Temperature-4 ~ 158?F (-20 ~ 70?C)
PackageBox
Power (Watts)960 mW
Product StatusActive
RPM8000 RPM
SeriesSan Ace 40
Size / DimensionSquare - 40mm L x 40mm H
Static Pressure0.319 in H2O (79.5 Pa)
Termination4 Wire Leads
Voltage - Rated24VDC
Voltage Range20.4 ~ 27.6VDC
Weight0.077 lb (34.93 g)
Width20.00mm

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomCarlton Bates Company4397599400713.381In StockSANYO DENKI13.38 @ 1
Digi-Key619115719.291In StockSanyo Denki America Inc.0.07719.29 @ 1
