DPDT Socket Mount Non-Latching Relay Plug In, 15 A, 12VDC
Weight:
0.836
Weight:
0.12 LB
Preferred Price:
16.12
Price:
16.12
Min Simple Price:
8.0
Absolute Min Price:
12.04
Min Price:
12.04
Dimensions:
[2.0, 2.0, 1.0]
qty:
21
simpleSku:
MTUyMQ:::RPM22JD
sku:
MTUyMQ::QN:RPM22JD@y0
condition:
11
seller:
Newark
amzMan:
cai - schneider electric
HazMat:
False
DropShip:
False

Attributes

Key ^Value
[Ie] Rated Operational Current, Amperage Rating15 A 277 V AC) UL || 15 A 28 V DC) UL || 15 A 250 V AC) NO IEC || 15 A 28 V DC) NO IEC || 7.5 A 250 V AC) NC IEC || 7.5 A 28 V DC) NC IEC
[Ithe] Conventional Enclosed Thermal Current15 A -40-55 ?C
[Uc] Control Circuit Voltage, Coil Voltage12 V DC
[Ui] Rated Insulation Voltage250 V IEC || 300 V CSA || 300 V UL
[Uimp] Rated Impulse Withstand Voltage4 kV 1.2/50 ?s
AC Contact Rating - Relay15 A @ 277V, 15A @ 277V
Ambient Air Temperature For Operation-40-55 ?C
Ambient Air Temperature For Storage-40-85 ?C
ApprovalsCE, CSA, UL
Average Coil Consumption0.85 W
Average Resistance160 Ohm at 20 ?C +/- 10 %
Base Type - Plug In RelaySquare
Body Depth1.54 in
Body Depth - Relay, Body Height1.06 in
Body Height - Relay, Overall Depth1.82 in
Body Width, Body Width - Relay0.83 in
Brand, Manufacturer, MfrSchneider Electric
California Proposition 65 : WARNING: This product can expose you to chemicals includingNickel compounds, which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Catalog Number, Item Number, Manufacturer Product Number, MpnRPM22JD
CategoryRelays
China Rohs RegulationX
Circularity ProfileN/A
Coil Current75 mA
Coil Insulation, Seal Rating-
Coil Resistance, Resistance160 OHMS
Coil TypeNon Latching
Coil Voltage12VDC
Coil Volts12V DC
ConnectionFLAT/SPADE (FASTON TYPE)
Contact Configuration, Contact Operation, Contacts Type And Composition2 C/O
Contact Current Rating, Contact Rating (Current), Current Rating, Max Current15 A
Contact FormDPDT (2 Form C)
Contact Form, Contact Form - Relay, ContactsDPDT
Contact MaterialSilver Nickel, Silver Nickel Alloy, Silver Nickel (AgNi), Silver Alloy
Contact RatingB300
Contact Voltage Rating300
Contacts Material, MaterialAgNi
Control Typelockable test button
Country of OriginCN - China, China
Current Stock197
DC Contact Rating - Relay15 A @ 28V, 15A @ 28V
DescriptionHARMONY, POWER PLUG-IN RELAY, 15
Detailed DescriptionGeneral Purpose Relay DPDT (2 Form C) 12VDC Coil Socketable
Device Presentationcomplete product
Device Short Name, Sub BrandRPM
Dielectric Strength1500 V AC between contacts with micro disconnection || 2000 V AC between coil and contact with reinforced || 2000 V AC between poles with basic
Digi-Key Part Number4008-RPM22JD-ND
Diode, International Shipping, Made in USA, Safety GuidedNo
Drop-Out Voltage Threshold>= 0.1 Uc DC
ECCNEAR99
Electrical Durability100000 cycles resistive
EnclosureIP 40 CONFORMING TO IEC/EN 60529, Plastic
Environmental DisclosureENVPEP1406038EN
Eu Rohs DirectivePro-active compliance (Product out of EU RoHS legal scope)
Family SeriesSquare D Relays
FeaturesPlug-In Protection Module to Protect Against Electrical Spikes, Plug In Protection Module to Protect Against Electrical Spikes, Lighted Indicator, Test Button
Flat Pin Width0.18 in
Gross Weight, Net Weight0 lbs
GTIN03389119401944
HP @ 120V, HP @ 240VNot Rated
Ip Degree Of ProtectionIP40 conforming to IEC 60529
Item TypePlug-in relay;Flat
Item, Item - RelayGeneral Purpose Relay
Lead TimeExpected to ship in 1-2 business days
Load Current15 A 250 V AC || 15 A 28 V DC
ManufacturerSquare D
Manufacturer Part Number589407
Manufacturer Standard Lead Time3 Weeks
Maximum Switching Capacity3750 VA || 420 W
Maximum Switching Voltage250 V IEC
Mechanical Durability10000000 cycles
Minimum Switching Capacity170 mW 10 mA, 17 V
MountingDin Rail
Mounting - Relay, TerminationPlug-In
Mounting - Relay, Termination StylePlug In
Mounting TypeSocket Mount, Socketable
Must Operate Voltage9.6 VDC
Must Release Voltage1.2 VDC
Net Weight0.036 kg
Nominal Coil Voltage, Published Coil Voltage12 VDC
Number of Pins - Relay8
Operate Time, Release Time20 ms
Operating Position, Special Featuresany position
Operating Temperature-40?C ~ 55?C, -40-55 A Degrees C
Operating Time, Reset Time20 ms at nominal voltage
Overall Height - Relay2.13 in
PackageBox
Pollution Degree3
Power Consumption - Relay0.9 W
Primary TypePower Relays
Product CertificationsCSA || UL || EAC
Product Or Component Typeplug-in relay
Product StatusActive
Protection CategoryRT I
Push To TestLockable
Push-to-Test, Reach Free Of Svhc, RoHS, Rohs Exemption Information, Status IndicatorYes
Range Of ProductHarmony Electromechanical Relays
Rated Operational Voltage Limits9.6...13.2 V DC
Reach RegulationFree of Substances of Very High Concern above the threshold
Relay TypeGeneral Purpose
Safety Reliability DataB10d = 100000
SeriesHarmony
Series NamePower
Shape Of Pinflat
Shock Resistance15 gnin operation || 30 gnnot operating
SKUZO-G2620536
Socket Code - RelayD
Standard15 GNIN OPERATION-30 GNNOT OPERATING,3 GN +/- 1 MM 10-150 HZ)5 CYCLES IN OPERATION-5 GN +/- 1 MM 10-150 HZ)5 CYCLES NOT OPERATING,CSA C22.2 NO 14-EN/IEC 61810-1-UL 508,CSA-UL-ROHS-REACH-EAC,IP40 EN/IEC 60529, CSA C22.2 No 14 || EN/IEC 61810-1 || UL 508
StandardsCSA C22.2 No 14, CSA Certified, EAC, EN/IEC 61810-1, UL 508, UL Listed, CSA C22.2 No 14 || IEC 61810-1 || UL 508, CE Marked, CSA, UL
Status IndicatorLED and Mechanical Flag
Status Ledwith
SubCategoryElectrical
Sustainable Offer StatusGreen Premium product
Switching Voltage250VAC, 28VDC - Max
Test Levelslevel A group mounting
UNSPSC39122326
UPC, UPC Code785901447924
Utilisation Coefficient20 %
Vibration Resistance3 gn +/- 1 mm 10-150 Hz)5 cycles in operation || 5 gn +/- 1 mm 10-150 Hz)5 cycles not operating
Warranty18 months
Warranty DescriptionContractual Warranty:18 months
