Attributes
| Key ^ | Value |
|---|---|
| Auxiliary Contact Rating | 10 A at 600 VAC, 5 A at 600 VDC |
| Coil Voltage | 110/120 |
| Connection type | Box Lug |
| Dimensions | 36 in H x 24 in W x 8 in D |
| Enclosure Type | NEMA 12 |
| Frequency Rating | 50/60 |
| Motor Power | 30 hp, 40 hp, 75 hp |
| Number of Poles | 3 |
| Operating Cycles | 5000000 |
| Operating Temperature | -4 to 104 |
| Overload Relay | Solid State |
| Reset Type | Automatic/Manual/Remote |
| Setting | 50 to 200 |
| Type | SZ 3-1/2 Class 18 Dust/Watertight Full Voltage Heavy Duty Non-Reversing Weatherproof |
| Voltage Rating | 575/600 |
