Attributes
| Key | Value |
|---|---|
| Amperage Rating | 75/76/78 |
| Application Type | Asynchronous Motor |
| Dimensions | 15.06 in H x 12.36 in W |
| Enclosure Type | IP55 |
| Frequency Rating | 50.8/59.1/67.5 |
| Horsepower | 49.62 hp, 54.98 hp, 60.35 hp |
| Insulation class | Class H |
| Mounting type | IM B3 |
| Phase | 3 |
| Series | 1PH8165 |
| Shaft Size | 55 mm Dia x 160 mm H |
| Speed | 1500/1750/2000 |
| Temperature Rating (Degrees F) | 104 |
| Torque Rating | 236/224/215 |
| Type | Compact Forced Ventilation |
| Voltage Rating | 350/400/440 |
