| Amperage Rating | 2 |
| Auxiliary Contact Rating | 1CO |
| Coil Voltage | 24 |
| Connection type | Screw, Screw Terminal, Terminal Screw |
| Dimensions | 100 mm H x 22.5 mm W x 141.6 mm D |
| Enclosure Type | IP20 |
| Frequency Rating | 50/60 |
| Full Load Current | 2 |
| Motor Power | 1/8 hp, 0.33 hp, 3/4 hp, 1/8 hp, 0.333 hp, 3/4 hp |
| Number of Poles | 3 |
| Operating Cycles | 30000000 |
| Operating Temperature | -25 to 60 |
| Overload Relay | Class 10A Electronic, Solid State, Solid-State |
| Phase | 3 |
| Series | 3RM1 |
| Setting | 0.4 to 2 |
| Timing | 65 to 76 ms On, 30 to 43 ms Off |
| Type | Direct On Line Fail Safe |
| Voltage Rating | 48 to 500 |
| Wattage | 0.09 to 0.75 |
