Attributes
| Key ^ | Value |
|---|---|
| Coil Power Rating | 2/40 VA, 1/23 W, 40 VA Pickup, 2 VA Holding, 23 W Closing, 1 W Holding |
| Coil Voltage | 175 to 280 |
| Contact Configuration | 1NO-1NC |
| Dimensions | 114 mm H x 55 mm W x 130 mm D, 55 mm W x 130 mm D x 114 mm H |
| Enclosure Type | IP00/IP20 |
| Frequency Rating | 50/60 |
| Mounting type | DIN Rail/Snap-On/Threaded, Surface/Threaded/DIN Rail/Snap-On |
| Number of Auxiliary Contacts | 2 |
| Number of Poles | 3 |
| Operating Cycles | 10000000 |
| Operating Temperature | -25 to 60 |
| Series | 3RT2 |
| Size | 2, S2 |
| Terminal Type | Screw |
| Type | Standard |
| Wattage | 22 |
