Attributes
| Key ^ | Value |
|---|---|
| Amperage Rating | 0.22 to 0.32 |
| Auxiliary Contact Rating | 1NO-1NC |
| Connection type | Screw |
| Dimensions | 97 mm H x 45 mm W x 96 mm D |
| Enclosure Type | IP20 |
| Frame | S00 |
| Frequency Rating | 50 to 60 |
| Interrupt Rating | 100 |
| Mounting type | DIN Rail |
| Number of Poles, Phase | 3 |
| Power Rating | 120 |
| Series | 3RV2 |
| Temperature Rating (Degrees F) | -20 to 60 |
| Trip Type | Magnetic |
| Voltage Rating | 690 |
| Wire Size | 18 to 14 |
