Attributes
| Key ^ | Value |
|---|---|
| Amperage Rating | 10/11/12.5 |
| Auxiliary Contact Rating | B300/R300 |
| Coil Voltage | 120/230 |
| Connection type | Spring Loaded Terminal |
| Control Type | Electronics |
| Dimensions | 150 mm H x 45 mm W x 154 mm D |
| Enclosure Type | IP20 |
| Frequency Rating | 50 to 60 |
| Motor Power | 7-1/2 hp, 10 hp |
| Number of Poles, Phase | 3 |
| Operating Temperature | -25 to 60 |
| Reset Type | External |
| Series | 3RW40 |
| Type | Basic Performance |
| Voltage Rating | 400 to 600 |
| Wattage | 5.5/7.5 |
