Description:
Illuminated Push Button, 30 mm, Maintained Pull / Maintained Push, Type of Operator 44mm Mushroom Head, Basic Material Epoxy, Metal Head Material, 1NO/1NC Contact Form, Black Epoxy Coated Zinc Die Cast Bezel, Color Green, Lamp Module Voltage 24V AC/DC, Lamp Module Type Full Voltage, Lamp Type Incandescent, Lamp Voltage 24V AC/DC, Replacement Lamp Mfr. No. 52AADN, Contact Rating 10A @ 600V AC, NEMA Contact Rating Designation A600/P600, Number of Operators 1, NEMA Rating 1, 12, 13, 3, 3R, 4, 4X
Attributes
| Key ^ | Value |
|---|---|
| Action | Maintained Pull / Maintained Push |
| Basic Material | Epoxy |
| Bezel | Black Epoxy Coated Zinc Die Cast |
| Color | Green |
| Contact Form, Contact Type | 1NO/1NC |
| Contact Rating | 10A @ 600V AC |
| Head Material | Metal |
| Item | Illuminated Push Button |
| Lamp Module Type | Full Voltage |
| Lamp Module Voltage, Lamp Voltage, Voltage | 24V AC/DC |
| Lamp Type | incandescent |
| NEMA Contact Rating Designation | A600/P600 |
| NEMA Rating | 1, 12, 13, 3, 3R, 4, 4X |
| Number of Operators | 1 |
| Replacement Lamp | Mfr. No. 52AADN |
| Size | 30 mm |
| Standards | UL,CSA |
| Terminal Connection | Pressure Plate |
| Type of Operator | 44mm Mushroom Head |
