| Cache Memory | 2 |
| Dimensions | 310 mm H x 415 mm W x 26 mm D |
| Display Type | 15 in TFT Touch |
| Environmental Conditions | 5 to 45 deg C Operating Temperature, 5 to 80% at 25 deg C Non-Condensation Relative Humidity |
| Expansion/Connectivity | 2 x PCI, 1 x PCI, 1 x PCIe (x16), 2 x PCIe (x4, (x16)), 4 x USB 3.0 |
| Hard Disk | 250 |
| Mounting type | Panel |
| Networking Specification | 2 x 10/100/1000 Mbps RJ45 Ethernet, 1 x COM 1 RS232 |
| Operating system | Windows? 7 Ultimate 32/64 bit |
| Power supply | 100/240 VAC, 24 VDC |
| Processor | Celeron G1820TE |
| Ram Memory | 2 GB DDR3 1600 DIMM |
| Series | IPC677D |
| Speed | 2.2 |
