SKF 1206ETN9

mpn1206 ETN9
brandname: SKF
manufacturername: SKF

SKF 1206 ETN9 Double Row Self-Aligning Bearing, ABEC 1 Precision, Open, Plastic Cage, Normal Clearance, Metric, 30mm Bore, 62mm OD, 16mm Width, 1050.0 pounds Static Load Capacity, 3510.00 pounds Dynamic Load Capacity

Brand: SKF
PartNumber: 1206ETN9
Model: 1206 ETN9
PackageQuantity: 1
Binding: Misc.
Manufacturer: SKF
Label: SKF

Attributes

Key	Value
ABEC Tolerance	1
Bearing Material	Steel
Bearing Type	Ball
Bore	1.181 Inch \| 30 Millime.
Bore Dia.	30 mm
Bore Diameter	30 mm
Bore Diameter Tolerance	+0/-0.010 mm
Bore Tolerance	+0/-.010mm
Bore Type	Cylindrical
Brand	SKF
Cage Material	Polyamide, PA66
Category - BDI	Self Aligning Ball Bear.
Closure Type	None
Current Stock	3
Dynamic Load Capacity	3,510 lb
EAN	7316576622243
Enclosure	Open
Fillet Radius	1 mm
Harmonized Tariff Code	8482.10.50.68
Inch - Metric	Metric
Inner Diameter	30 mm
Inner Race Width	0.63 Inch \| 16 Millimet.
Internal Clearance	C0-Medium, CN
International Shipping	No
Item	Self-Aligning Ball Bear.
Keyword String	Self Aligning
Lead Time	Expected to ship in 1-2.
Long Description	30MM Bore; Shaft Mount;.
Lubrication	Shell Alvania Grease
Manufacturer Item Number	1206 ETN9
Manufacturer Name	SKF
Max. Load Axial	323 lb
Max. RPM	15,000 RPM
Minimum Buy Quantity	N/A
Mounting Method	Shaft
Mpn	1206 ETN9
Noun	Bearing
Number of Rows	Double
Number of Rows of Balls	Double Row
O.D. (in)	2 4/9
Other Features	Allowable Misalignment .
Outer Diameter	62 mm
Outer Race Width	0.63 Inch \| 16 Millimet.
Outer Ring Width	16 mm
Outside Dia.	62 mm
Outside Dia. Tolerance	+0/-.013mm
Outside Diameter	2.441 Inch \| 62 Millime.
Outside Diameter Tolera.	+0/-0.013 mm
Overall Width	16 mm
Precision Class	ABEC 1 \| ISO P0
Product Group - BDI	B00152
Rolling Element	Ball Bearing
Seal/Shield Type	Open
Single Row/Double Row	Double Row
SKU	ZO-G9418017
Static Load Capacity	1,050 lb
Static Load Rating	4.63 kN
SubCategory	Power Transmission
Temp. Range	-40 Degrees to 210 Deg.
UNSPSC	31171532
UPC Code	7316576622243
Weight / Kilogram	0.22
Weight / LBS	0.485
Width	16 mm

All Prices

Seller	Supplier SKU	Min Price	MOQ	In Stock	Brand	Weight	Preferred Tier
RS Delivers	285-1305	37.8	1	In Stock	SKF		37.8 @ 1
MRO Supply	319014	47.23	1	In Stock	SKF Bearing		47.23 @ 1
BDI Express	1418607	53.22153466	1	12	SKF	0.484	53.22153466 @ 1
us.rs-online.com	73219169	67.75	1	In Stock	SKF Bearings		67.75 @ 1
Purvis	1206 ETN9	71.56	1	In Stock	SKF		71.56 @ 1
Zoro	G9418017	85.5	1	1	Skf	0.51	85.5 @ 1
simsupply.com	ZO-G9418017	86.85	1	3	Skf		86.85 @ 1
motionindustries.com	00042443	90.35	1	In Stock	SKF		90.35 @ 1
