SKF 21314 E/C3

B007VHN0O8

SKF 21314 E/C3 Spherical Radial Bearing, Straight Bore, Steel Cage, C3 Clearance, 70mm Bore, 150mm OD, 35mm Width

SKF 21314 E/C3 Spherical Radial Bearing, Straight Bore, Steel Cage, C3 Clearance, 70mm Bore, 150mm OD, 35mm Widthzoom

Attributes

Key Value
Adapter Part NumberNot Applicable Inch | N.
Bearing TypeSpherical Roller
Bore2.756 Inch | 70 Millime.
Bore Dia. (In.)2.7559 in
Bore Dia. (mm)70 mm
Bore Diameter70 mm
Bore ProfileStraight
Bore TypeCylindrical
CageSheet metal
Cage MaterialSteel
Category - BDISpherical Roller Bearing
Dynamic Load Capacity (.64,100 lb
Dynamic Load Capacity (.285,000 N
EAN7316577732620
EnclosureOpen
Fillet Radius2 mm
Harmonized Tariff Code84823080
I.D.2 3/4 in
Inch - MetricMetric
Inner Diameter70 mm
Internal ClearanceC3, C3-Loose
ItemSpherical Roller Bearing
Keyword StringSpherical
Long Description70MM Straight Bore; 150.
Lubricant MaterialGrease
LubricationGrease
Manufacturer NameSKF
MaterialBearing steel
Max. Temperature(?C)200 ?C
Minimum Buy QuantityN/A
Mounting MethodShaft Mount
NounBearing
Number of Rows of Rolle.Double Row
O.D. (in)5 8/9
Outer Diameter150 mm
Outside Dia. (In.)5.9055 in
Outside Dia. (mm)150 mm
Outside Diameter5.906 Inch | 150 Millim.
Overall Width35 mm
Product Group - BDIB04311
RelubricatableYes
Ring Material Grade100Cr6
Roller MaterialAlloy Steel
Roller Material Grade100Cr6
Rolling ElementSpherical Roller Bearing
Seal MaterialNot Applicable
Series213 Series
Static Load Capacity (L.73,000 lb
Static Load Capacity (N)325,000 N
Temp. Range (F)0 Degrees to 392 Degre.
TypeDouble Row
UNSPSC31171510
UPC Code7316577732620
Weight / Kilogram3.173
Weight / LBS6.979
Width1.378 Inch | 35 Millime.
Width (In.)1.378 in
Width (mm)35 mm
Withdrawal NutNot Applicable
Withdrawal SleeveNot Applicable

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomAmazonB007VHN0O8212.181In StockSKF212.18 @ 1
thumbzoomMRO Supply323369254.821In StockSKF Bearing254.82 @ 1
thumbzoomBDI Express1421898266.1830579114SKF6.9806266.18305791 @ 1
RS Delivers207-8395321.181In StockSKF321.18 @ 1
us.rs-online.com73222621338.8511SKF Bearings338.85 @ 1
thumbzoomMisumi USA21314 E/C3343.171In Stock27SKF343.17 @ 1
Grainger36ME14358.01In Stock15SKF358.0 @ 1
thumbzoomZoroG9419191366.991In StockSkf7.04366.99 @ 1
motionindustries.com00062721451.751In StockSKF451.75 @ 1
