| Air Cylinder Bore Dia., Bore Dia. | 20 mm |
| Air Cylinder Mount, Mount | Basic |
| Air Cylinder Type | Round Body |
| Body Material, End Cap Material, Piston Rod Material, Tube Material | Stainless steel |
| Country of Origin (subject to change) | United States |
| Cushion Type, Features | Air Cushion |
| Cylinder Action, Single Acting/Double Acting | Double Acting |
| Cylinder Type | Round |
| Dimension A, Overall Length | 318 mm |
| Dimension B | 31mm |
| Dimension C | 35mm |
| Item | Air Cylinder |
| Magnetic Piston | No |
| Max. Pressure | 145 psi |
| Piston Material | Non-Magnetic |
| Port Size | M5 x 0.8 in |
| Rod Dia. | 8 mm |
| Rod Thread Length | 18 mm |
| Rod Thread Size | M8 x 1.25 in |
| Stroke | 200 mm |
| Temp. Range | 14 Degrees to 140 Degrees F |
| Tie Rod Material | N |
