mpn:
manufacturer:
MPN:
Weight:
3.0
Weight:
0.211875 LB
Preferred Price:
285.87
Price:
285.87
Min Simple Price:
161.51
Absolute Min Price:
229.34
Min Price:
229.34
Dimensions:
[10.0, 7.0, 5.0]
qty:
21
simpleSku:
DY0NDY:::QBL22125
sku:
DY0NDY::RZ:QBL22125@y0
condition:
11
seller:
mostelectric.com
amzMan:
cai - square d
HazMat:
False
DropShip:
False
Attributes
| Key ^ | Value |
|---|---|
| AC Voltage Rating | 240V AC |
| Amperage Rating | 125 |
| Amps, Current Rating | 125 A |
| Application | PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION |
| Brand | Square D, Square D by Schneider Electric |
| Catalog Number, Mpn | QBL22125 |
| Circuit Breaker Actuator | Toggle |
| Circuit Breaker Mounting Style | Free Standing |
| Circuit Breaker Type | Standard |
| Connection | LINE: LUG - LOAD: LUG |
| Country of Origin | MX - Mexico, Mexico |
| Current Rating | 125-125A |
| Current Stock | 3 |
| DC Voltage Rating | Not Rated |
| Depth | 3.93 in. |
| Depth, Length | 3.93 in |
| ECCN | EAR99 |
| Frame Size | 250A/QB |
| Frame Type | Q Frame |
| Frame, Frame Type | Q-Frame |
| Frequency Rating | 50/60HZ |
| Gtin, UPC, Upc, UPC Code | 785901412557 |
| Height | 6.47, 6.47 in., 6.47 in |
| Height UOM, Width UOM | Inch |
| High Amp Trip Setting | 2,400 A |
| Instantaneous Trip | Fixed |
| International Shipping, Made in USA | No |
| Interrupt Rating | 10KA@240VAC, 10kA |
| Item, Item Type | Molded Case Circuit Breaker |
| Lead Time | Expected to ship in 1-2 business days |
| Length | 22 mm |
| Low Amp Trip Setting | 1,200 A |
| Manufacturer | Schneider Electric |
| Max. AIR Rating | 10 kA at 240V AC, 10kA at 240V AC |
| Max. Wire Size | 300 MCM |
| Min. Wire Size | 4 AWG |
| No. of Poles, Number of Poles | 2 |
| Operating Temperature | -13F AND 158F (-25 C AND +70 C) |
| Phase | Single |
| Phase Connection | Not Applicable |
| Rated Voltage | 240V AC 50/60 Hz UL |
| Series | Q-Frame Series, QB, QBL |
| SKU | ZO-G0624854 |
| Special Features | UNIT MOUNT |
| Standard | UL LISTED - CSA CERTIFIED - IEC RATED, UL || CSA || NEMA || NOM-003-SCFI-2000 |
| Standards | CSA, IEC, UL Listed, RoHS Compliant |
| Sub Brand | POWERPACT |
| SubCategory | Electrical |
| Terminal Connection | Line/Load Lug |
| Torque | 28-28 N.m 25-150 mm? (AWG 4...300 kcmil) |
| Trip Range | HOLD: 1200A - TRIP: 2400A |
| Trip Type | THERMAL-MAGNETIC, Thermal Magnetic |
| Type | Thermal/Magnetic |
| UNSPSC | 39121616 |
| Voltage Rating | 240 V, 240 VAC |
| Warranty Description | Contractual Warranty:18 months |
| Width | 3 mm, 3.0, 4.5 in |
All Prices
| Img | Seller | Supplier SKU | Requested Price ^ | Calc MOQ Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|---|---|---|---|---|---|---|---|---|---|
 | mostelectric.com | QBL22125 | 161.51 | 161.51 | 1 | In Stock | SQUARE D/TELEMECANIQUE | 161.51 @ Qty: 1+ | ||
| AmazonSC | B000E20RCK | 189.99 | 189.99 | 1 | In Stock | Square D | 189.99 @ Qty: 1+ | |||
 | Radwell | QBL22125 | 210.0 | 210.0 | 1 | In Stock | SCHNEIDER ELECTRIC SQUARE D | 210.0 @ Qty: 1+ | ||
 | Newark | 89H5585 | 240.85 | 240.85 | 1 | In Stock | SQUARE D BY SCHNEIDER ELECTRIC | 240.85 @ Qty: 1+ | ||
| Graybar | 22067427 | 269.7408 | 269.7408 | 1 | 1 | Square D (Schneider Electric) | 269.7408 @ Qty: 1+ | |||
 | sustainablesupply.com | C1195560 | 280.29 | 280.29 | 1 | In Stock | Square D | 3.39 | 280.29 @ Qty: 1+ | |
 | simsupply.com | ZO-G0624854 | 285.11 | 285.11 | 1 | 3 | Square D | 285.11 @ Qty: 1+ | ||
 | Zoro | G0624854 | 295.99 | 295.99 | 1 | 1 | Square D | 3.39 | 295.99 @ Qty: 1+ | |
| simplybreakers.com | QBL22125 | 312.99 | 312.99 | 1 | In Stock | Schneider Electric | 312.99 @ Qty: 1+ | |||
 | superbreakers.com | QBL22125 | 389.89 | 389.89 | 1 | In Stock | Square D | 389.89 @ Qty: 1+ | ||
| standardelectricsupply.com | 993432 | 481.52 | 481.52 | 1 | In Stock | Square D | 481.52 @ Qty: 1+ | |||
| us.rs-online.com | 70953780 | 535.97 | 535.97 | 1 | In Stock | Square D | 535.97 @ Qty: 1+ | |||
 | Raptor Supplies | AG6QEH | 589.201002 | 589.201002 | 1 | In Stock | SQUARE D | 589.201002 @ Qty: 1+ | ||
 | crescentelectric.com | 144561 | 680.91 | 680.91 | 1 | In Stock | Square D by Schneider Electric | 680.91 @ Qty: 1+ | ||
| grainger.ca | SQDQBL22125 | 1025.49855546 | 1025.49855546 | 1 | In Stock | SQUARE D | 3.1 | 1025.49855546 @ Qty: 1+ |
