Schneider Electric HJL26030C

B00CONIMAQ

SCHNEIDER ELECTRIC HJL26030C Molded Case Circuit Breaker 600-Volt 30A Electrical Box

SCHNEIDER ELECTRIC HJL26030C Molded Case Circuit Breaker 600-Volt 30A Electrical Boxzoom

Attributes

Key Value
[Ics] Rated Service Bre.100 kA 220/240 V AC 50/.
[Ue] Rated Operational .690 V AC 50/60 Hz IEC 6.
[Ui] Rated Insulation V.750 V IEC 60947-2
[Uimp] Rated Impulse Wi.8 kV IEC 60947-2
Ambient Air Temperature.-2-70 ?C
Ambient Air Temperature.-50-85 ?C
Awg GaugeAWG 14...AWG 3/0 alumin.
Breaking Capacity100 kA 240 V AC 50/60 H.
Breaking Capacity CodeJ
California Proposition .DINP, which is known to.
China Rohs RegulationProduct out of China Ro.
Circularity ProfileENVEOLI1311006EN
ColorBlack
Communication InterfaceModbus || Ethernet
Continuous Current Rati.100 %
Control Typetoggle
Depth86 mm
Device Applicationdistribution
Electrical Connectionlugs line || lugs load
Environmental DisclosureENVPEP1311006EN
Eu Rohs DirectiveCompliant
Height163 mm
Ip Degree Of Protectionfront cover IP40 IEC 60.
Line Rated Current30-30 A
Local Signallingswitched off (OFF) 1 tr.
Magnetic Hold Current350 A
Magnetic Tripping Curre.750-750 A
Mercury FreeYes
Mounting Modeunit mount lug)
Mounting Supportlug
Net Weight2.2 kg
Network Frequency50/60 Hz
Number Of Slots2 auxiliary switch OF p.
Poles Description2P
Pollution Degree3 IEC 60947-1
Product CertificationsUL || CSA || NOM
Product NamePowerPact H
Product Or Component Ty.circuit breaker
Protected Poles Descrip.2t
Pvc FreeYes
Quality LabelsCE
Quantity Per Set1
RangePowerPact
Reach RegulationReference contains Subs.
Rohs Exemption Informat.Yes
StandardsUL || CSA || NEMA || NO.
Suitability For Isolati.yes IEC 60947-2
Sustainable Offer StatusGreen Premium product
Terminal IdentifierAL150HD
Tightening Torque5-5 N.m 2.5-6 mm? (AWG .
Trip Unit Technologythermal-magnetic
Utilisation Categorycategory A
Warranty18 months
Width104 mm
Wire Stripping Length16 mm

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomgordonelectricsupply.comHJL26030C1645.01In Stock10SQUARE D1645.0 @ 1
thumbzoomRadwellHJL26030C1750.01In StockSCHNEIDER ELECTRIC SQUARE D1750.0 @ 1
thumbzoommayerelectric.comSQDHJL26030C1790.911In StockSQUARE D4.841790.91 @ 1
