SWITCHCRAFT/CONXALL HS2P9M26

B07696KL4P

Circular Connector, Dura-Pull HS Series, Panel Mount Receptacle, 9 Contacts, Crimp/Solder Pin

Circular Connector, Dura-Pull HS Series, Panel Mount Receptacle, 9 Contacts, Crimp/Solder Pinzoom

Attributes

Key Value
ApplicationsAgriculture, Audio, Gen.
Backshell Material, Pla.-
Base Product NumberHS2P9M
Cable Opening-
CategoryConnectors, Interconnec.
ColorSilver
Connector TypePanel ; Front Mount, Re.
Contact Finish - MatingGold
Contact Finish Thicknes.-
Contact MaterialCopper Alloy
Contact Size26 AWG
Current Rating (Amps)-
DescriptionCONN RCPT MALE 9POS GOL.
Detailed Description9 Position Circular Con.
Digi-Key Part NumberSC2273-ND
Family NameDura-Pull
Fastening TypePush-Pull
Features-
GenderMale
Ingress ProtectionIP66/IP67/IP68 - Dust T.
Insert MaterialLiquid Crystal Polymer .
IP RatingIP68
ManufacturerSwitchcraft Inc.
Manufacturer Product Nu.HS2P9M26
Manufacturer Standard L.10 Weeks
Material Flammability R.UL94 HF-1
MfrSwitchcraft Inc.
Mounting FeatureBulkhead - Rear Side Nut
Mounting TypePanel Mount
Number of Contacts9
Number of Positions9
Operating Temperature-40?C ~ 135?C
OrientationKeyed
PackageBulk
Primary MaterialMetal
Primary TypePush Pull
Product StatusActive
SeriesHS Dura-Pull Series, Du.
Shell FinishElectroless Nickel
Shell MaterialCopper Alloy
Shell Size - Insert-
Shell Size, MIL-
ShieldingShielded
TerminationCrimp or Solder Cup
TypeSealed
Voltage Rating30VAC/DC

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
AdoramaSWHS2P9M2619.421In StockSwitchcraft19.42 @ 1
Hawk ElectronicsHS2P9M2620.325In StockSwitchcraft20.3 @ 25
thumbzoomDigi-Key597487622.21189Switchcraft Inc.22.21 @ 1
us.rs-online.com7093118722.43195Switchcraft22.43 @ 1
thumbzoomNewark84Y303225.2425In StockSWITCHCRAFT/CONXALL25.24 @ 25
