TB Woods AK2878

B003N17K2E

TB Woods AK2878 FHP Bored-to-size V-Belt Sheave, A Belt Section, 1 Groove, 7/8" Bore, Cast Iron, 2.85" OD, 8780 max rpm

TB Woods AK2878 FHP Bored-to-size V-Belt Sheave, A Belt Section, 1 Groove, 7/8" Bore, Cast Iron, 2.85" OD, 8780 max rpmzoom

Attributes

Key Value
3L Pitch Diameter2.51 in
3V Pitch DiameterNot Applicable
3VX Pitch DiameterNot Applicable
4L Pitch Diameter2.85 in
5V Pitch DiameterNot Applicable
5VX Pitch DiameterNot Applicable
A Pitch Diameter2.85 in
AX Pitch Diameter2.85 in
B Pitch DiameterNot Applicable
Belt sectionA-4L-3L
Belt Section Size3L ; 4L ; A
Bore Diameter7/8 in
Bore TypeFixed
Bore typeFinished with keyway
Bore-to-size bore diame.0.88
Bore-to-size keyseat3/16 in x 3/32 in
BrandTb Woods
BX Pitch DiameterNot Applicable
C Pitch DiameterNot Applicable
ColorGrey
Component WR2 (lbs ft2)0.00
Current Stock47
CX Pitch DiameterNot Applicable
Datum diameter2.6
Dimension0.44
Face Width0.66 in
Face width0.66
Face width (in)0.66
For Belt Trade Size3L, 4L, A, AX
For V-Belt TypeClassical, Cogged
Groove cross section se.A
Hub location-0.44
Hub location (in)-0.44
Hub Projection0.44 in
Hub TypeOne Side
I.D.2.48
IncludesSet Screw
Inertia WR?1
Inside diameter (in)2.48
International ShippingNo
ItemStandard V-Belt Pulley
KeywayYes
Keyway Depth3/32 in
Keyway Width3/16 in
Length through Bore15/16 in
MaterialCast Iron
Material FabricationCast
Material typeCI
Max RPM8780
Maximum Bore Diameter1 in
MpnAK2878
Number of Grooves1
Number of grooves1
O.D.2.85
Outer Diameter2.85 in
Outside Diameter2.85 in
Outside diameter (in)2.85
Overall Width1 1/8 in
Pitch diameter2.85
Pitch Diameter2.85 in
Pulley ConstructionWebbed
RPM upper limit8780
SeriesFHP AK Series
SKUZO-G2390814
StandardsISO 9001:2015
SubCategoryPower Transmission
UPC698672091145
UPC Code698672091145
Weight0.9 lb

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoombscsource.comAK287812.891In StockTB Wood's12.89 @ 1
grainger.caWWG5RHZ815.408861381In StockTB WOOD'S0.7315.40886138 @ 1
thumbzoomsimsupply.comZO-G239081418.62147Tb Woods18.62 @ 1
Grainger5RHZ819.011060TB WOOD'S19.0 @ 1
thumbzoomNational Supply Network8222288623.491In StockTB Wood's23.49 @ 1
thumbzoomsustainablesupply.comC268267224.331In StockTB Wood's0.7324.33 @ 1
thumbzoomMRO Supply34567525.893In StockTB Woods25.89 @ 3
thumbzoomRaptor SuppliesAE6FKP28.4477311In StockTB WOODS28.447731 @ 1
us.rs-online.com7167038229.311In StockTB Wood's (Altra)29.31 @ 1
