TE Connectivity / AMP 1-5747871-6

B083MZT89H

1-5747871-6, Plug Assembly, Size 1, 9 POS, Vertical, Front Shell, AMPLIMITE HDP (25 Items)

1-5747871-6, Plug Assembly, Size 1, 9 POS, Vertical, Front Shell, AMPLIMITE HDP (25 Items)zoom

Attributes

Key Value
AngleStraight
Approved StandardsUL E28476
Backset Spacing-
Base Product Number5747871
CategoryConnectors, Interconnec.
Centerline (Pitch)2.74?mm?[?.108?in?]
Circuit ApplicationSignal
ColorBlack
ConnectorPrinted Circuit Board
Connector Mounting TypeBoard Mount
Connector StylePlug, D-Sub
Connector SystemBoard-to-Board
Connector TypePlug, Male Pins
Contact Base MaterialBrass
Contact Current Rating .6
Contact FinishGold
Contact Finish Thickness-
Contact Form-
Contact MaterialBrass
Contact PlatingGold
Contact ShapeRound
Contact TypeSignal
Contact Underplating Ma.Nickel
Country of Origin (subj.Mexico
Current Rating (Amps)6A
DescriptionCONN D-SUB PLUG 9POS VE.
Detailed Description9 Position D-Sub Plug, .
Dielectric MaterialThermoplastic
Digi-Key Part NumberA34092-ND
FeaturesGrounding Indents
Flange FeatureMating Side, Female Scr.
Housing MaterialThermoplastic
Ingress Protection-
ManufacturerTE Connectivity AMP Con.
Manufacturer Product Nu.1-5747871-6
Manufacturer Standard L.4 Weeks
Material Flammability R.UL94 V-0
Mating Connector LockWith
Mating Connector Lock T.Female Screwlocks, Fixed
MfrTE Connectivity AMP Con.
Mounting TypeThrough Hole
Number of Contacts9
Number of Positions9
Number of Rows2
Operating Temperature-55?C ~ 105?C
Operating Temperature R.-55 ? 105??C?[?-67 ? 22.
PackageTube
Panel Mount FeatureWithout
PCB Contact Termination.Tin
PCB Mount OrientationVertical
PCB Mount RetentionWith
PCB Mount Retention TypeMounting Hole
PCB Mounting StyleThrough Hole
Primary TypeD-Sub
Product StatusActive
ProfileStandard
Row-to-Row Spacing.112 in, 2.84 mm
SealableNo
SeriesHD-20 Series, AMPLIMITE.
Shell MaterialFront Metal Shell
Shell Material, FinishSteel, Tin Plated
Shell Size1
Shell Size, Connector L.1 (DE, E)
Shell TypeFront Metal Shell
StandardsUL94 V-0
TerminationSolder, Through Hole
TypePCB Plug
Voltage Rating125V
Wire Gauge-
Wire Size20 AWG

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
WaldomTE CONNECTIVITY AMP BRAND 1-5747871-63.6317484TE CONNECTIVITY/AMP BRAND3.63 @ 17
Onlinecomponents.com1-5747871-64.1915900TE Connectivity / AMP Brand4.19 @ 10
TE Connectivity1-5747871-64.94871971TE Connectivity (TE)4.9487 @ 10
us.rs-online.com700855115.38107110TE Connectivity5.38 @ 1071
thumbzoomZoroG7010405005.58107110Te Connectivity5.58 @ 1071
Newark41AJ10416.0117467AMP - TE CONNECTIVITY6.01 @ 10
thumbzoomDigi-Key11238686.0712889TE Connectivity AMP Connectors6.07 @ 10
RS Delivers795-2210P9.276139TE Connectivity9.276 @ 10
AmazonTPB00DJUI5Y612.281102T-E Connectivity12.28 @ 10
AmazonUNKB00DJUI5Y612.28110T-E Connectivity12.28 @ 10
