Attributes
| Key ^ | Value |
|---|---|
| Application | Power, Signal |
| Color | Black |
| Connection Material | Tin |
| Connector Terminates To | Printed Circuit Board |
| Contact Finish | Noble Metal Plated |
| Contact Plating Thickness | 0.076 ?m |
| Contact Type | Pin |
| Current Rating | 42 A |
| Flammability Rating | UL 94 V-0 |
| Hole Center to Center | 6.35 mm; 2.54 mm |
| Item | Header |
| Material | High Temperature Thermoplastic |
| Max. Temp. | 105?C |
| Max. Voltage | 200V AC/DC |
| Number of Contacts | 30 |
| Number of Rows | 4 |
| Package Quantity | 1 |
| Terminal Finish | Tin Plated |
| Terminal Type | Through Hole - Solder |
